Template examples - the full list

latest update 2024-04-17

Introduction

In this topic a full list of examples of template instances is given for quick review and SPARQL testing purposes.

The list

@prefix ex: <http://www.example.org/>.
@prefix exrdl: <http://www.example.org/rdl>.
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix rdfs: <http://www.w3.org/2000/01/rdf-schema#> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@prefix skos: <http://www.w3.org/2004/02/skos/core#> .
@prefix dm: <http://data.15926.org/dm/> .
@prefix lci: <http://data.15926.org/lci/> .
@prefix tpl: <http://data.15926.org/tpl/> .
@prefix rdl: <http://data.15926.org/rdl/> .
@prefix meta: <http://data.15926.org/meta/> .
@prefix cfihos: <http://data.15926.org/cfihos/> .
@prefix api: <http://data.15926.org/api/> .
@prefix asme: <http://data.15926.org/asme/> .
@prefix astm: <http://data.15926.org/astm/> .
@prefix br: <http://www.baker-and-raas.org/>.
@prefix fwc: <http://www.fw.corp/>.
@prefix xyz: <http://www.xyz.ltd.org/>.

#### LIST OF EXAMPLE TEMPLATE INSTANCES AS SHOWN IN THE TEMPLATE SPECIFICATIONS

Templates about one or more ClassOfIndividuals, related to:


#Templates about one or more ClassOfIndividuals, related to: ACTIVITY

# CL-ACTIV-100.xml # EXAMPLE - Any member of ClassOfActivity HYDROSTATIC TESTING # has one of more members of the ClassOfPhysicalObject PRESSURE-RATED ARTEFACT as a participant # in the Role of HYDROSTATICALLY TESTED OBJECT. ex:aede4554-5804-4c6a-8810-b06d97aa5dae rdf:type tpl:ClassOfParticipationDefinition ; tpl:hasActivityType rdl:RDS9706787 ; # HYDROSTATIC TESTING tpl:hasParticipantType rdl:RDS430694 ; # PRESSURE RATED ARTEFACT tpl:hasParticipantRole rdl:RDS2221129 ; # HYDROSTATICALLY TESTED OBJECT tpl:hasCardinalityOfActivity rdl:RDS999900701 ; # ONE TO MANY tpl:hasCardinalityOfParticipant rdl:RDS222625 ; # ONE TO ONE meta:hasLifecyclActivity rdl:RDS2226942 ; # CONSTRUCTION meta:valEffectiveDate "2021-11-17T15:23:56Z"^^xsd:dateTime . # CL-ACTIV-150.xml # EXAMPLE - Any member of ClassOfActivity "Pumping Lean Amine to E-103" # has a member of the ClassOfPhysicalObject CO-P-101 (CENTRIFUGAL PUMP) as a participant in the Role of PERFORMER, # and a member of the ClassOfStream CO-STR-4283 as a participant in the Role of SUBJECT. ex:1665062e-6413-4b1c-bae9-f61e57941013 rdf:type tpl:ClassOfDualParticipationDefinition ; tpl:hasActivityType ex:2567e250-6a3c-4b17-a4eb-bf65f926b9c0 ; # Pumping Lean Amine to E-103 tpl:hasParticipantType1 ex:48cfb847-f385-463f-b3a3-f5960c8ad7da ; # P-101 Requirements Class CO-P-101 tpl:hasParticipantRole1 rdl:RDS222365 ; # PERFROMER tpl:hasParticipantType2 ex:b6d27ff3-dc7d-4d57-b2ce-1170f09936bf ; # CO-STR-4283 Lean Amine Stream tpl:hasParticipantRole2 rdl:RDS222362 ; # SUBJECT meta:hasLifecycleActivity rdl:RDS2229995 ; # PLANT DESIGN meta:valEffectiveDate "2021-07-17T13:27:00Z"^^xsd:dateTime . # CL-ACTIV-155.xml # EXAMPLE - Any member of ClassOfActivity INSTALLING has (or has not) # a member of the ClassOfPhysicalObject CO-P-101-M-rev0 (driver of P-101) as a participant in the Role of SUBJECT, # and a member of the ClassOfOrganization MANUFACTURER as a participant in the Role of PERFORMER . # NOTE - This is a prompt on a specification for pumps, where the driver is purchased separately. ex:a1e6ac72-79df-4fff-8f38-237e38c79953 rdf:type tpl:ClassOfDualParticipationDefinitionYN ; tpl:hasActivityType rdl:RDS9664127 ; # INSTALLING tpl:hasParticipantType1 ex:4a620c9a-62db-4b87-b8ee-e11396149a8a ; # Requirements Class CO_B14-P101-M-rev0 for driver of P-101 tpl:hasParticipantRole1 rdl:RDS222362 ; # SUBJECT tpl:hasParticipantType2 rdl:RDS4242650 ; # MANUFACTURER tpl:hasParticipantRole2 rdl:RDS222365 ; # PERFORMER tpl:hasApplicableYesNo "TRUE"^^xsd:boolean ; meta:hasLifecycleActivity rdl:RDS9709622 ; # DETAILED ENGINEERING meta:valEffectiveDate "2022-02-17T10:29:00Z"^^xsd:dateTime . # CL-ACTIV-200 # EXAMPLE - Stress analysis is not applicable to the supports of Line class CO_RZ17801. ex:4b97deaa-4b14-41aa-a92c-aad805fa8402 rdf:type tpl:ClassOfParticipationNotApplicable ; tpl:hasActivityType rdl:RDS2229907 ; # ANALYSING STRESS tpl:hasParticipantType ex:2ba11bf4-4192-4ec4-8d8f-903898c3dd7e ; # the supports of Line CO_RZ17801 tpl:hasParticipantRole rdl:RDS222362 ; # DIRECT OBJECT tpl:valApplicableYesNo "false"^^xsd:boolean ; meta:valEffectiveDate "2021-07-17T13:27:00Z"^^xsd:dateTime . # CL-ACTIV-250 # EXAMPLE - Any member of ClassOfActivity [WELDING TO AWS D1.1] # has a member of the [WELDER] class [AWS CERTIFIED WELDER] as a participant in the Role of [PERFORMER], # and a member of the [INSTRUCTION] class [AWS D1.1] as an involved-by-reference object in the Role of [INSTRUCTION(role)]. ex:f175f71f-d23e-4d97-b937-50b7cad17671 rdf:type tpl:ClassOfParticipationAndInvolvementByReferenceDefinition ; tpl:hasActivityType rdl:RDS2229974 ; # WELDING TO AWS D1.1 tpl:hasParticipantType rdl:RDS2229956 ; # AWS CERTIFIED WELDER tpl:hasParticipantRole rdl:RDS222365 ; # PERFROMER tpl:hasInvolvedType rdl:RDS2229955 ; # AWS D1.1 tpl:hasInvolvementRole rdl:RDS2220036 ; # INSTRUCTION(role) meta:valEffectiveDate "2021-07-17T15:07:00Z"^^xsd:dateTime . # CL-ACTIV-300.xml # EXAMPLE - API standard 1104 is involved by reference # in a member of activity class 'Welding of Line CO_RZ17801' in the role of 'Applicable Standard'. ex:494ce008-7d3f-4cf5-89b7-7591e200d214 rdf:type tpl:ClassOfInvolvementByReferenceDefinition ; tpl:hasActivityType rdl:RDS9651347 ; # WELDING tpl:hasInvolvedType api:RDS2229952 ; # API 1104 tpl:hasInvolvementRole rdl:RDS2229953 ; # APPLICABLE STANDARD tpl:hasCardinalityOfActivity rdl:RDS222625 ; # ONE TO ONE tpl:hasCardinalityOfInvolved rdl:RDS222625 ; # ONE TO ONE meta:valEffectiveDate "2021-07-17T16:34:00Z"^^xsd:dateTime . # CL-ACTIV-310.xml # EXAMPLE - API standard 1104 is not involved by reference # in a member of activity class 'Welding of Line CO_RZ17801' in the role of 'Applicable Standard'. ex:494ce008-7d3f-4cf5-89b7-7591e200d214 rdf:type tpl:ClassOfInvolvementByReferenceNotApplicable ; tpl:hasActivityType ex:e84a6f9f-2478-4c87-ba32-54e8116a9d65 ; # Welding of Line CO_RZ17801 tpl:hasInvolvedType api:RDS2220052 ; # API 1104 tpl:hasInvolvementRole rdl:RDS2229953 ; # APPLICABLE STANDARD meta:valEffectiveDate "2021-07-17T16:34:00Z"^^xsd:dateTime . # CL-ACTIV-500.xml # EXAMPLE - The corrosion rate of members of requirements class CO_KE-104 for corrosion electrode KE-104 # is recognized by members of the ClassOfActivity "MEASURING CORROSION RATE". ex:83e84006-6f05-4574-84fd-0200bae2c425 rdf:type tpl:ClassOfRecognitionDefinition ; tpl:hasActivityType rdl:RDS2223284 ; # MEASURING CORROSION RATE tpl:hasRecognized ex:f4ef9c43-2de4-4fd9-8ca0-bab086d4e17f ; # Template representing "Any member of [CORROSION MEASURING ELEMENT] class [CO_KE-104] has a [CORROSION RATE] of [] [MILLIMETRE PER YEAR]" tpl:hasDefined ex:a80d5a08-823e-4a8a-bc8a-72b878497a61 ; # auto-generated tpl:hasCardinalityOfActivity rdl:RDS222625 ; # ONE TO ONE tpl:hasCardinalityOfRecognized rdl:RDS222625 ; # ONE TO ONE meta:valEffectiveDate "2021-07-17T21:34:00Z"^^xsd:dateTime . # CL-ACTIV-600.xml # EXAMPLE - Any member of ClassOfActivity 'STARTING AN ARTEFACT' # begins the operational state of any member of the Class 'ARTEFACT IN OPERATION' ex:28d5c5ca-1124-4c3d-a7c2-70cd3f714f46 rdf:type tpl:ClassOfCauseOfBeginningOfClassOfIndividualDefinition ; tpl:hasActivityType rdl:RDS2229946 ; # STARTING AN ARTEFACT tpl:hasIndividualType rdl:RDS2229948 ; # ARTEFACT IN OPERATION tpl:hasCardinalityOfActivity rdl:RDS999900701 ; # ONE TO MANY tpl:hasCardinalityOfIndividual rdl:RDS222625 ; # ONE TO ONE meta:valEffectiveDate "2021-07-18T08:05:00Z"^^xsd:dateTime . # CL-ACTIV-700.xml # EXAMPLE - Any member of ClassOfActivity 'STOPPING AN ARTEFACT' # ends the operational state of any member of the Class "ARTEFACT IN OPERATION'' ex:ea73dea0-4523-400f-b093-7a5e90b35a64 rdf:type tpl:ClassOfCauseOfEndingOfClassOfIndividualDefinition ; tpl:hasActivityType rdl:RDS2229947 ; # STOPPING AN ARTEFACT tpl:hasIndividualType rdl:RDS2229948 ; # ARTEFACT IN OPERATION tpl:hasCardinalityOfActivity rdl:RDS999900701 ; # ONE TO MANY tpl:hasCardinalityOfIndividual rdl:RDS222625 ; # ONE TO ONE meta:valEffectiveDate "2021-07-18T08:05:00Z"^^xsd:dateTime .

#Templates about one or more ClassOfIndividuals, related to: CLASSIFICATION

# CL-CLSIF-100.xml # EXAMPLE - Any instance of ClassOfInanimatePhysicalObject 'TRANSFORMER' # is classified as an 'ELECTRICAL EQUIPMENT CLASS'. ex:ac8b013b-60fa-4864-a384-14d1e711d81f rdf:type tpl:ClassificationOfClassOfIndividual ; tpl:hasClassified rdl:RDS643994 ; # TRANSFORMER tpl:hasClassifier rdl:RDS7160353 ; # ELECTRICAL EQUIPMENT CLASS meta:valEffectiveDate "2021-07-18T08:05:00Z"^^xsd:dateTime . # CL-CLSIF-200.xml # EXAMPLE - DISTILLING is not an intermittent operation. ex:3cd1871c-c2eb-472e-a351-1e8f9a72af28 rdf:type tpl:ClassificationOfClassOfIndividualNotApplicable ; tpl:hasClassified rdl:RDS9677447 ; # DISTILLING tpl:hasClassifier rdl:RDS9705752 ; # INTERMITTENT OPERATION meta:valEffectiveDate "2021-07-18T10:18:00Z"^^xsd:dateTime .

#Templates about one or more ClassOfIndividuals, related to: SPECIALIZATION

# CL-SPECN-100.xml # EXAMPLE - The P-101 Requirements Class CO-P-101 # is a specialization of the class that is defined with the, yet empty, API 610 Centrifugaal Pump Datasheet. ex:39cc0db1-f8f2-467f-a310-b8a053fefab0 rdf:type tpl:SpecializationOfClassOfIndividual ; tpl:hasSubClass fwc:6d300d37-9bea-4333-a377-589f8993c1ef ; # The offered pump class (of which one member may be sold, if successful) tpl:hasSuperClass fwc:PGY-43x ; # pump model PGY-43x in the catalog of the Forwarder Company meta:valEffectiveDate "2021-07-18T09:34:00Z"^^xsd:dateTime . # CL-SPECN-200.xml # EXAMPLE - Members of CO-PT101 are not devices with transient protection. ex:b1827e41-3ee2-4e66-a326-cdedb48eabe9 rdf:type tpl:SpecializationOfClassOfIndividualNotApplicable ; tpl:hasSubClass ex:e05062b3-3120-48c1-8545-186c1bfa4c3b ; # CO-PT101 , the Requirements Class for pressure transmitter PT101 tpl:hasSuperClass rdl:RDS2223270 ; # ELECTRICAL APPARATUS PROTECTED FROM TRANSIENTS meta:valEffectiveDate "2021-07-18T10:46:00Z"^^xsd:dateTime .

#Templates about one or more ClassOfIndividuals, related to: DEFINITION

# CL-DEFN-080.xml # EXAMPLE - The INDUSTRY ASSOCIATION CLASS 'API CLASS' is, externally, # defined in RDL terms, UK English Language, and ASCII as "An <API CLASS> # is an <INDUSTRY ASSOCIATION CLASS> that groups Classes that have been defined by the American Petroleum Institute (API)." ex:358434ff-399b-4746-916c-122da5129304 rdf:type tpl:DefinitionOfClassOfClass ; tpl:hasDefined api:RDS213749 ; tpl:hasDefinition "An is an that groups Classes that have been defined by the American Petroleum Institute (API)." ; tpl:hasDefinitionType exrdl:R68483 ; # definition in RDL terms, UK English Language, and ASCII meta:valEffectiveDate "2022-07-18T11:13:00Z"^^xsd:dateTime . # CL-DEFN-160.xml # EXAMPLE - Pump requirements class CO-P-101 # is defined on a specification in accordance with the 'XYZ Corp. Equipment Properties Definition for Pumps in US English Language and in ASCII'. ex:6e2d7930-6528-4cb4-bf24-04457b14a35f rdf:type tpl:DefinitionOfClassOfIndividual ; tpl:hasDefined ex:d1c615ac-8e96-4e31-ba8e-9b5a5f135fa8 ; # CO-P-101 tpl:hasDefinition "(definition text)" ; tpl:hasDefinitionType exrdl:R26344 ; # ["Shall contain details about: ATEX category, ATEX explosive atmosphere, ATEX group, bearing lubrication, dry weight, efficiency, explosion protection concept, explosion protection examination certificate number, explosion protection gas group, explosion protection material group, explosion protection notified body, explosion protection temperature class, explosion protection zone, ingress protection, lower limit allowable temperature,net positive suction head required, normal operating outlet pressure, normal volume flow rate, operating weight, rated inlet pressure, rated power consumption, rated speed, rated volume flow rate, seal type, upper limit allowable pressure, upper limit allowable speed, and upper limit allowable temperature."] meta:valEffectiveDate "2021-07-18T11:13:00Z"^^xsd:dateTime . # CL-DEFN-200.xml # EXAMPLE - The requirements class CO-P-142 # is defined with a placehoder called 'CFIHOS Tag Class Properties for RotaryPumps' # that collects a defining template set. ex:3cfe58cb-a1c6-4aa4-8b17-87f3449a22cc rdf:type tpl:DefinitionOfClassOfIndividualWithInfoSet ; tpl:hasDefined ex:391fdd02-f0cb-4f67-8578-149f79ca7869 ; # the Asset Requirements Class CO-P-142 tpl:hasTemplateSet ex:cd87e752-c198-49f0-9c75-6e56d96a4fe5 ; # the collecting EnumeratedSetOfClass tpl:hasInfoSet ex:b45c6be6-dcc9-4c5e-a0f3-8e10abb45fd8 ; # the placeholder of the result of intersecting the collected classes tpl:hasInfoSetType exrdl:R32674 ; # 'CFIHOS Tag Class Properties for RotaryPumps' meta:valEffectiveDate "2022-07-18T16:23:00Z"^^xsd:dateTime . # CL-DEFN-480.xml # EXAMPLE - Defining a ClassOfFunctionalMapping for head calculation of a centrifugal pump with an equation. ex:58377d27-2530-44c7-9cb7-9f45a8cb4623 rdf:type tpl:DefinitionOfClassOfRelationship ; tpl:hasDefined rdl:RDS2227340 ; # the ClassOfFunctionalMapping called "CENTRIFUGAL PUMP HEAD EQUATION" tpl:hasDefinition "[MathML code for head equation]" ; tpl:hasDefinitionType exrdl:R68372 ; # Head Calc Definition in MathML and ASCII meta:valEffectiveDate "2022-01-01T15:00:00Z"^^xsd:dateTime . # CL-DEFN-560.xml # EXAMPLE - Radioactive Material is marked with the IAEA sign for radiation ex:2ab54823-82f1-4b32-86d7-55d8db42e1a4 rdf:type tpl:DefinitionOfClassOfIndividualWithClassifiedSign ; tpl:hasDefined rdl:RDS2223127 ; # RADIOACTIVE MATERIAL tpl:hasSign ex:db00b18a-3c35-43c8-bcb6-aa9aec798304 ; # Actual physical sign tpl:hasSignType rdl:RDS2223124 ; # IAEA SIGN meta:valEffectiveDate "2021-07-18T14:20:00Z"^^xsd:dateTime . # CL-DEFN-640.xml # EXAMPLE - Define the ClassOfMultidimensionalObject that classifies the MultidimensionalProperty "Q-H" on the Q-H curve. ex:2d90aecd-1c57-4934-ad19-427d2c237e3d rdf:type tpl:DefinitionOfClassOfMultidimensionalObjectWith2Roles ; tpl:hasDefined ex:4cf312d7-85d1-49fd-b625-7be10437b9bf ; # Q-H POINT tpl:hasRole1 rdl:RDS2225808 ; # THROUGHPUT(role) tpl:hasDomain1 rdl:RDS380834 ; # VOLUME FLOW RATE tpl:hasRole2 rdl:RDS2225809 ; # HEAD(role) tpl:hasDomain2 rdl:RDS361574 ; # DIFFERENTIAL PRESSURE meta:valEffectiveDate "2021-07-18T14:20:00Z"^^xsd:dateTime . # CL-DEFN-720.xml # EXAMPLE - Definition of the RoleAndDomain with domain 'API 1104' and role 'APPLICABLE STANDARD'. ex:a98fb76c-36da-4506-b146-6e4d5d846dd8 rdf:type tpl:DefinitionOfRoleAndDomain ; tpl:hasDomain api:RDS2229952 ; # API 1104 tpl:hasRole rdl:RDS2229953 ; # APPLICABLE STANDARD tpl:hasDefined ex:R123456 ; # 'API 1104' AND 'APPLICABLE STANDARD' (in local RDL extension) meta:valEffectiveDate "2021-07-19T11:20:00Z"^^xsd:dateTime . # CL-DEFN-800.xml # EXAMPLE - Definition of the ParticipatingRoleAndDomain with domain 'PUMP' and role 'PERFORMER' ex:a98fb76c-36da-4506-b146-6e4d5d846dd8 rdf:type tpl:DefinitionOfParticipatingRoleAndDomain ; tpl:hasDomain rdl:RDS327239 ; # PUMP tpl:hasRole rdl:RDS222365 ; # PERFORMER tpl:hasDefined ex:R654321 ; # 'PUMP' and 'PERFORMER' (in local RDL extension) meta:valEffectiveDate "2021-07-19T11:20:00Z"^^xsd:dateTime . # CL-DEFN-900.xml # EXAMPLE - Members of a Pump class in a quotation by Bloggs Ltd # are intended to play the Role of 'REQUIRED OBJECT' of members of Requirement Class CO-P-101. ex:4c1184b8-7220-455d-b91c-67760d36b459 rdf:type tpl:ClassOfIntendedRoleAndDomainDefinition ; tpl:hasPlayerType ex:a61410ca-7d4b-441d-aa44-0e87fc791c3b ; # Pump class in a quotation by Bloggs Ltd tpl:hasPlayedType ex:3d3f9d2e-d61d-4da5-9469-445f7addb5eb ; # Requirement Class CO-P-101 tpl:hasPlayedRole rdl:RDS2225807 ; # REQUIRED OBJECT tpl:hasDefined ex:c9d7575a-3f7f-4b05-bba8-587aa253205a ; # auto-generated tpl:hasCardinalityOfPlayedType rdl:RDS999900701 ; # ONE TO MANY tpl:hasCardinalityOfPlayerType rdl:RDS999900701 ; # ONE TO MANY meta:valEffectiveDate "2022-11-17T15:23:56Z"^^xsd:dateTime .

#Templates about one or more ClassOfIndividuals, related to: DESCRIPTION

# CL-DESCR-100.xml # EXAMPLE - Progress Report PR-43328 rev 14 # is described by its information content, the content type, language and format, # which are in compliance with 'Progress Report Definition in English Language and in ASCII' defined by the XYZ Corp. ex:9cb7ddd6-3b6f-4fc9-9b1b-8dfc08133e48 rdf:type tpl:ClassifiedDescriptionOfClassOfIndividual ; tpl:hasDescribed ex:868fd09b-cd03-4993-bd6a-e484218f5f33 ; # the report (elsewhere declared) tpl:hasDescriptor "(contents of Progress Report PR-43328-rev.14)" ; tpl:hasDescriptorType exrdl:R25236 ; meta:valEffectiveDate "2022-07-17T16:34:00Z"^^xsd:dateTime . # CL-DESCR-400.xml # EXAMPLE - Description of B+R model EXE/TE2212/S IP66 Explosion Protected Enclosure # with a nameplate (the text on that nameplate is defined separately) ex:b21bef63-4427-4cf2-9a3b-32623ff14328 rdf:type tpl:DescriptionOfClassOfIndividualWithClassifiedSign ; tpl:hasDescribed br:R549834 ; # the enclosure shown in the B+R catalog tpl:hasSign ex:92c02e77-9c9c-4312-aacc-8966c60f88c0 ; # the actual physical nameplate tpl:hasSignType rdl:RDS2229092 ; # NAMEPLATE meta:valEffectiveDate "2021-07-18T14:20:00Z"^^xsd:dateTime .

#Templates about one or more ClassOfIndividuals, related to: DOCUMENT

# CL-DOCS-100.xml # EXAMPLE - A PID SYMBOL has Information Contents and Presentation Details, # as defined in the related templates as, respectively, # "PID SYMBOL for Heat Exchanger (general) # to ISO 10628-2 REGNO X8079, in Java and in SVG format" and "LINE WEIGHT OF 1PT" ex:c34ca3b0-b106-4840-bd67-5479509615d4 rdf:type tpl:ClassOfCompositionDefinition ; tpl:hasClassOfWhole ex:2875f374-ef5d-4b32-bb3e-514e3aa1db7c ; # shared with first template tpl:hasClassOfPart rdl:RDS2225784 ; # LINE WEIGHT 1 PT tpl:hasDefined ex:ba6d7315-d33d-4d9f-94dc-14aeb3292d38 ; tpl:hasCardinalityOfWhole rdl:RDS222625 ; # ONE TO ONE tpl:hasCardinalityOfPart rdl:RDS222625 ; # ONE TO ONE meta:valEffectiveDate "2021-07-19T12:16:00Z"^^xsd:dateTime . # CL-DOCS-150.xml # EXAMPLE - The API 610 PUMP DATA SHEET has contents # that are defined by the API 610 PUMP DATA SHEET DEFINITION. ex:4bac287b-2708-4a00-b19e-df8500b3fce7 rdf:type tpl:DefinitionOfDocumentByContentsType ; tpl:hasDocument ex:f50e142d-613a-4985-afe3-334b0c7d4d90 ; # PL-43322-rev1 tpl:hasContentsType api:RDS345689 ; # API 610 PUMP DATA SHEET DEFINITION meta:valEffectiveDate "2021-07-20T15:07:00Z"^^xsd:dateTime . # CL-DOCS-200.xml # EXAMPLE - The API 610 PUMP DATA SHEET has contents that are in the US English Language ex:b378e58c-9fbf-4144-a6f2-f6767fc9cfb4 rdf:type tpl:DefinitionOfDocumentByLanguage ; tpl:hasDocument ex:f50e142d-613a-4985-afe3-334b0c7d4d90 ; # PL-43322-rev1 tpl:hasLanguage rdl:RDS11369220 ; # US ENGLISH LANGUAGE meta:valEffectiveDate "2021-07-20T15:07:00Z"^^xsd:dateTime . # CL-DOCS-250.xml # EXAMPLE - The API 610 PUMP DATA SHEET has contents that are in ASCII format. ex:99bf795d-9a97-4a43-adea-7ad2be97e626 rdf:type tpl:DefinitionOfDocumentContentsFormat ; tpl:hasDocument ex:f50e142d-613a-4985-afe3-334b0c7d4d90 ; # PL-43322-rev1 tpl:hasFormat rdl:RDS2221127 ; # ASCII meta:valEffectiveDate "2021-07-20T15:07:00Z"^^xsd:dateTime . # CL-DOCS-260.xml # EXAMPLE - Members of document type "PIPING ISOMETRIC DRAWING" # shall have thePDF format before the START OF FABRICATION (in CFIHOS data model) ex:08681d94-e770-4822-b04c-03f6d57ef24b rdf:type tpl:ClassOfInformationObjectHasFormatBeforeClassOfEvent ; tpl:hasDocument ex:83d25886-83da-4975-8ff6-7149fd772e8e ; # Isometric Fr-47383-rev2 tpl:hasFormat rdl:RDS2224723 ; # PDF tpl:hasEventType rdl:RDS2227312 ; # START OF FABRICATION meta:valEffectiveDate "2021-07-20T15:07:00Z"^^xsd:dateTime . # CL-DOCS-265.xml # EXAMPLE - Members of document type "ISOMETRIC" # shall have thr PDF format after the PROJECT COMPLETION EVENT (in CFIHOS data model) ex:5370aa91-998d-4923-97e8-c6ec622600af rdf:type tpl:ClassOfInformationObjectHasFormatAfterToClassOfEvent ; tpl:hasDocument rdl:RDS331559 ; # PIPING ISOMETRIC DRAWING tpl:hasFormat rdl:RDS2224723 ; # PDF tpl:hasEventType rdl:RDS2225344 ; # PROJECT COMPLETION EVENT meta:valEffectiveDate "2021-07-20T15:07:00Z"^^xsd:dateTime . # CL-DOCS-350.xml # EXAMPLE - The contents of API 610 data sheet for CO-P-142 with number PL-43322-rev1 # can be found via a reference to the ISO 15926-8 file that contains the contents of that data sheet ex:aa9962b7-a027-4b8b-831a-fe4819d2f0fc rdf:type tpl:ContentsOfADocument ; tpl:hasDocument ex:5e602e34-31f2-43ac-bef0-2ce96983ff70 ; # API 610 data sheet for CO-P-142 tpl:hasContents ex:fbdbe82a-a7ef-4d0a-8ed1-83cc9646a7ab ; # the UUID of the applicable instance of DetailingOfInformationRepresentation template. tpl:hasContentType exrdl:R38493 ; meta:valEffectiveDate "2021-07-20T17:03:00Z"^^xsd:dateTime . # CL-DOCS-450.xml # EXAMPLE - A Pipe Sketch is not applicable for Line CO-RZ17801 ex:f04dfdcd-575f-4af2-a4d7-fa2384711bf0 rdf:type tpl:DocumentTypeNotApplicableForClassOfIndividual ; rdfs:label "Any member of [PROCESS LINE] class [CO-RZ17801] is not represented on a [DRAWING] class [PIPE SKETCH]"@en ; tpl:hasIndividualType ex:df9d8d63-c05d-4f51-a5fc-5177e6ad6c65 ; # Line CO-RZ17801 tpl:hasDocumentType rdl:RDS2229908 ; # PIPE SKETCH tpl:valApplicableYesNo "false"^^xsd:boolean ; meta:valEffectiveDate "2021-07-24T17:27:00Z"^^xsd:dateTime . # CL-DOCS-500.xml # EXAMPLE - Asset Requirements Class Line CO-RZ17802 # is shown on Line List 22212-rev2, just for cross-reference ex:b84f315e-498a-4e81-8f05-826d1f422efa rdf:type tpl:ReferenceToClassOfIndividualOnDocument ; tpl:hasReferred ex:4fb4bd78-974b-48f5-a10f-b79e9b4d4afb ; # Asset Requirements Class Line CO-RZ17802 tpl:hasDocument ex:730ebe49-7713-47bc-b152-658df6aa65f2 ; # Line List 22212-rev2 meta:valEffectiveDate "2021-07-26T14:54:00Z"^^xsd:dateTime . # CL-DOCS-525.xml # EXAMPLE - Asset Requirements Class for Line CO-RZ1780 # is represented on Line List 22212-rev2, just for cross-reference # in a given type of representation (here an ISO 15926-8 file in ASCII) ex:9383a3fa-9fe4-468a-a7f0-42e05218e05e rdf:type tpl:RepresentationOfClassOfIndividualOnDocument ; tpl:hasReferred ex:e779a1ce-2038-47c5-a5d9-a97df0df3e26 ; # CO-RZ1780 tpl:hasDocument ex:ff007d41-3445-45ef-b5b6-b7eb67b968d8 ; # 22212-rev2 tpl:hasRepresentation ex:3f5ce0dd-168e-477c-947f-531d90f91d63 ; meta:valEffectiveDate "2021-07-26T15:23:00Z"^^xsd:dateTime . # CL-DOCS-800.xml # EXAMPLE - The contents of a Valve Specification SP-43589 rev.1 # are defined by a, separately defined, set of classes (mostly templates), # that represent the information contained in the data elements of that specification. # NOTE - both the hasContent and the has hasSetOFClass can be detailed in separate templates ex:e7f55635-d594-4f35-bc2f-2183461bd073 rdf:type tpl:DefinitionOfDocumentContentWithSetOfClass ; tpl:hasDocument ex:34b17f8d-a41e-4956-9ac3-69e080d6a970 ; # SP-43589 rev.1 tpl:hasContent ex:ad1d91f9-e53b-49f6-b4fc-67785be23d11 ; # The UUID of the information content (no data) tpl:hasSetOfClass ex:843207cb-0169-40df-8680-46ef1f3d4c63 ; # the placeholder of the set meta:valEffectiveDate "2021-10-27T00:00:00Z"^^xsd:dateTime . # CL-DOCS-850.xml # EXAMPLE - This text has been translated from English to Russian. ex:864d8e8b-c7ab-4067-81b2-422cba0d9211 rdf:type tpl:TranslationOfClassOfInformationRepresentation ; tpl:hasContentsIn ex:e8893ece-afde-40f5-8891-6552f3ff90fe ; # input English text tpl:hasContentsTypeIn exrdl:R546372 ; # Text in UK English and ASCII (user-defined) tpl:hasContentsOut ex:40b46b5d-7798-45ec-9c94-2c46fcb0d66c ; # translated Russian text tpl:hasContentsTypeOut exrdl:R546377 ; # Text in Russian and Cyrillic (user-defined) meta:valEffectiveDate "2021-07-26T16:57:00Z"^^xsd:dateTime . # CL-DOCS-860.xml # EXAMPLE - A translation of text in Pump Specification PS1234 is required. ex:faf34007-6b5a-486a-88fb-5c8d529e3e6b rdf:type tpl:TranslationOfClassOfInformationObjectRequiredYesNo ; tpl:hasTranslationInput ex:9ce67c42-c291-4b64-9d25-1331ca5e711a ; # the text in Pump Specification PS1234 tpl:valRequiredYesNo "true"^^xsd:boolean ; meta:valEffectiveDate "2021-07-31T15:24:00Z"^^xsd:dateTime . # CL-DOCS-900.xml # EXAMPLE - Members of EQUIPMENT SPECIFICATION must be made available as hard copy. ex:e42c7635-8f54-4f48-bba2-30ee546d47de rdf:type tpl:HardcopyOfDocumentRequiredYesNo ; tpl:hasDocumentType rdl:RDS222282 ; # EQUIPMENT SPECIFICATION tpl:hasMaterial rdl:RDS2228947 ; # PAPER SUBSTRATE tpl:valRequiredYesNo "true"^^xsd:boolean ; meta:valEffectiveDate "2021-08-01T11:48:00Z"^^xsd:dateTime .

#Templates about one or more ClassOfIndividuals, related to: EXISTENCE

# CL-EXIST-100.xml # EXAMPLE - Line List LL12345-rev2 is a class-of-temporal-part of 'anchor' Line List LL12345 . ex:455ca3c1-c625-4352-a5d7-0772e54c449a rdf:type tpl:ClassOfTemporalWholePartDefinition ; tpl:hasTemporalWhole ex:3e3186d2-ffaa-4c8a-b5df-bed38ebf6f5b ; # LL12345 tpl:hasTemporalPart ex:76b01303-b644-41a0-8565-b4f100cc3abc ; # LL12345-rev2 meta:valEffectiveDate "2021-07-26T15:59:00Z"^^xsd:dateTime . # CL-EXIST-300.xml # EXAMPLE - Activity ACT45983 caused the 'anchor' of drawing Nb4393 has become effective NOTE - Normally done with metadata meta:valEffectiveDate ex:16481910-7dd7-4c2a-b48d-3378dd9ebcf8 rdf:type tpl:ActivityCausesEffectiveClassOfIndividual ; tpl:hasActivity ex:a20fcae7-2b1f-4f74-b387-c11162a8f57d ; # ACT45983 tpl:hasEffectiveClass ex:d6976e3b-031c-4bcd-8aa8-89f34bb39a71; # Nb4393 meta:valEffectiveDate "2021-08-01T15:27:00Z"^^xsd:dateTime . # CL-EXIST-500.xml # EXAMPLE - PFD Nb4393-rev1 has become deprecated by ACT59774 NOTE - Normally done with metadata meta:valDeprecationDate ex:2b75ecac-5831-4c71-a772-d3583249cd9d rdf:type tpl:ActivityCausesDeprecatedClassOfIndividual ; tpl:hasActivity ex:9e9e0f14-971f-4bd3-806e-70afbd8f0efb ; # ACT59774 tpl:hasDeprecated ex:5054ca59-013f-4dfa-b09a-00cb1e68173f ; # Nb4393-rev1 meta:valEffectiveDate "2021-08-14T09:34:00Z"^^xsd:dateTime .

#Templates about one or more ClassOfIndividuals, related to: FUNCTION

# CL-FUNC-100.xml # EXAMPLE - The bore of an orifice plate has a surface of 3018 mm2, # and the cross section of the NPS4/Sch40 pipe, in which it is mounted, is 8209 mm2, # therefore the beta ratio is 3018/8209=0.3676 ex:ef9adfab-1026-4e7e-962d-6ed0f5019875 rdf:type tpl:FunctionalMappingOf2ExpressReals ; tpl:hasInput1 "3018"^^xsd:decimal ; tpl:hasInput2 "8209"^^xsd:decimal ; tpl:hasResult "0.3676"^^xsd:decimal ; tpl:hasFunction rdl:RDS11566410 ; # FUNCTION DIV meta:valEffectiveDate "2021-08-17T13:19:00Z"^^xsd:dateTime . # CL-FUNC-200.xml # EXAMPLE - In the formula for mass liquid flow: m=C*A*sqrt(2*Density*(Pupstream-Pdownstream)) # there are three variables, a Density of 1237 kg/m3, # a Pupstream of 111.8 kPa, and a Pdownstream of 110.3 kPa, # and the result m is 65.9 kg/s. ex:70fe17ad-0e5c-4679-b129-e4a8e8143416 rdf:type tpl:FunctionalMappingOf3ExpressReals ; tpl:hasInput1 "1237"^^xsd:decimal ; tpl:hasInput2 "111.8"^^xsd:decimal ; tpl:hasInput3 "110.3"^^xsd:decimal ; tpl:hasResult "65.9"^^xsd:decimal ; tpl:hasFunction rdl:RDS2228370 ; # MASS FLOW EQUATION meta:valEffectiveDate "2021-08-14T16:38:00Z"^^xsd:dateTime . # CL-FUNC-300.xml # EXAMPLE - A warehouse has four temperature measurements and a calculated average of that. ex:bcad3a8d-a2b6-4e24-a278-4143d4756a16 rdf:type tpl:FunctionalMappingOf4ExpressReals ; tpl:hasInput1 "16.9"^^xsd:decimal ; tpl:hasInput2 "17.5"^^xsd:decimal ; tpl:hasInput3 "17.3"^^xsd:decimal ; tpl:hasInput4 "19.0"^^xsd:decimal ; tpl:hasResult "17.675"^^xsd:decimal ; tpl:hasFunction rdl:RDS11567220 ; # FUNCTION AVER meta:valEffectiveDate "2021-08-17T14:43:00Z"^^xsd:dateTime . # CL-FUNC-400.xml # EXAMPLE - Five variables in the head calculation of a centrifugal pump: h = 1000*(p2 - p1)/(ρ*g) + v2^2/(2*g) # resulting in a head of 32.12 ex:c76936c1-cf5f-4ace-8ddb-73bb5032fc59 rdf:type tpl:FunctionalMappingOf5ExpressReals ; tpl:hasInput1 "211.8"^^xsd:decimal ; tpl:hasInput2 "584.3"^^xsd:decimal ; tpl:hasInput3 "1237"^^xsd:decimal ; tpl:hasInput4 "5.3"^^xsd:decimal ; tpl:hasInput5 "9.81"^^xsd:decimal ; tpl:hasResult "32.12"^^xsd:decimal ; tpl:hasFunction rdl:RDS2227340 ; # CENTRIFUGAL PUMP HEAD EQUATION meta:valEffectiveDate "2021-08-18T12:58:00Z"^^xsd:dateTime .

#Templates about one or more ClassOfIndividuals, related to: IDENTIFICATION

# CL-IDENT-100.xml # EXAMPLE - The Requirements Class for line RZ17891 is identified as 'CO-RZ17801' # in accordance with the (user-defined) class exrdl:R582392 'Line Class Number Definition in ASCII' ". ex:5614d381-2c84-4932-a13c-2b2e8b025fb9 rdf:type tpl:ClassifiedIdentificationOfClassOfIndividual ; tpl:hasIdentified ex:df92e566-7981-4ba8-ab7a-7deddee9ae52 ; # CO-RZ-17801 tpl:hasIdentifier "CO-RZ17801" ; tpl:hasIdentifier exrdl:R582392 ; # 'Line Class Number Definition in ASCII' ; meta:hasLifecycleActivity rdl:RDS2229995 ; # PLANT DESIGN meta:valEffectiveDate "2021-08-18T17:13:00Z"^^xsd:dateTime .

#Templates about one or more ClassOfIndividuals, related to: INDIRECT PROPERTY

# CL-INDPTY-200.xml # EXAMPLE - Any member of MEDIUM SPEED DIESEL ENGINE # has a ROTATIONAL SPEED # with a range # that has a LowerBound of 360 rpm # and an UpperBound of 600 rpm ex:c1c8a46f-4c0a-482d-8e64-4883bba6ffb6 rdf:type tpl:ClassOfIndividualHasIndirectPropertyRange ; tpl:hasPossessorType rdl:RDS13291342 ; # MEDIUM SPEED DIESEL ENGINE tpl:hasPropertyType rdl:RDS361034 ; # ROTATIONAL SPEED tpl:valLowerBound "360"^^xsd:decimal ; tpl:valUpperBound "600"^^xsd:decimal ; tpl:hasScale rdl:RDS1342304 ; # REVOLUTION PER MINUTE meta:valEffectiveDate "2021-10-22T16:58:00Z"^^xsd:dateTime . # CL-INDPTY-210.xml # EXAMPLE - The QH curve of the class CENTRIFUGAL PUMP CO-P-1O1 # has VOLUME FLOW RATE with a range of 0 - 530 gpm # and a HEAD with a range of 35 - 108 ft. # NOTE - All values apply to the stream through that pump. ex:ae78f944-0802-4da8-bc99-cfcde74fb0c2 rdf:type tpl:ClassOfIndividualHasTwoDimensionalIndirectPropertyRange ; tpl:hasPossessorType ex:2a92adcc-dbf6-4e9e-b765-34a66b12602c ; # e.g. The requirements class of P-101 tpl:has2DPropertySpaceType rdl:RDS2223147 ; # Q-H CURVE RANGE tpl:hasPropertyType1 rdl:RDS380834 ; # VOLUME FLOW RATE tpl:valLowerBound1 "0"^^xsd:decimal ; tpl:valUpperBound1 "539"^^xsd:decimal ; tpl:hasScale1 rdl:RDS1346759 ; # US GALLONS PER MINUTE tpl:hasPropertyType2 rdl:RDS362609 ; # HEAD tpl:valLowerBound2 "35"^^xsd:decimal ; tpl:valUpperBound2 "108"^^xsd:decimal ; tpl:hasScale2 rdl:RDS1324664 ; # FOOT meta:valEffectiveDate "2021-10-23T12:40:00Z"^^xsd:dateTime . # CL-INDPTY-300.xml # EXAMPLE - The air in the Requirements Class of Photographic Materials Storage Room CO-B-357 # has a MAXIMUM RELATIVE HUMIDITY of 90 PERCENT ex:f28bd844-105e-4fdf-9126-04f24ed98965 rdf:type tpl:ClassOfIndividualHasIndirectPropertyWithMaximumValue ; tpl:hasPossessorType ex:3abc4c46-f80a-4448-8cc6-e5ee3b4fae79 ; # CO-B-357 tpl:hasIndirectPropertyType rdl:RDS2223547 ; # MAXIMUM RELATIVE HUMIDITY tpl:valMaximumValue "90"^^xsd:decimal ; tpl:hasScale rdl:RDS1317959 ; # PERCENT meta:valEffectiveDate "2021-10-24T16:38:00Z"^^xsd:dateTime . # CL-INDPTY-400.xml # EXAMPLE - Any member of the Requirements Class for Vessel CO-V-102 # has a NOMINAL CAPACITY (volume) of 25 m3. ex:1a1044a4-0111-4e05-837f-cd1856336a9c rdf:type tpl:ClassOfIndividualHasIndirectPropertyWithValue ; tpl:hasPossessorType ex:aa716e49-3630-49ff-b605-c2d172b978e9 ; # CO-V-102 tpl:hasIndirectPropertyType rdl:RDS2228787 ; # NOMINAL CAPACITY (volume) tpl:valPropertyValue "25"^^xsd:decimal ; tpl:hasScale rdl:RDS1349099 ; # METRE CUBED meta:valEffectiveDate "2021-08-17T15:23:00Z"^^xsd:dateTime . # CL-INDPTY-500.xml # EXAMPLE - The air in the Requirements Class of Photographic Materials Storage Room CO-B-357 # shall have a LOWER LIMIT ALLOWABLE TEMPERATURE of -20 DEGREE CELSIUS ex:f4deb0a3-217e-4afb-b0ab-1b1444321720 rdf:type tpl:ClassOfIndividualHasIndirectPropertyWithMinimumValue ; tpl:hasPossessorType ex:3abc4c46-f80a-4448-8cc6-e5ee3b4fae79 ; # CO-B-357 tpl:hasIndirectPropertyType rdl:RDS2228786 ; # LOWER LIMIT ALLOWABLE TEMPERATURE tpl:valMinimumValue "-20"^^xsd:decimal ; tpl:hasScale rdl:RDS1322684 ; # DEGREE CELSIUS meta:valEffectiveDate "2021-10-24T16:38:00Z"^^xsd:dateTime . # CL-INDPTY-700.xml # EXAMPLE - Any member of Pump Model 1520-5BC # has a CAPACITY (volume flow rate) of 530 gpm # when its impeller has a Rotational Speed of 1150 rpm. ex:1247af38-5e33-4e31-a93d-aae56bb41b17 rdf:type tpl:ClassOfIndividualHasConditionalIndirectPropertyWithValue ; tpl:hasMultidimensionalPropertyType rdl:RDS2225972 ; tpl:hasPossessorType ex:d3bdc308-7179-424c-918f-8c1fd743c970 ; # Pump Model 1520-5BC tpl:hasIndirectPropertyType rdl:RDS7354248 ; # CAPACITY (volume flow rate) tpl:valPropertyValue "530"^^xsd:decimal ; tpl:hasScale rdl:RDS1346759 ; # US GALLON PER MINUTE tpl:hasConditionPossessorType ex:f14ce469-1822-477c-b99a-7dd1ea2709ce ; # 1520-5BC-IMP (impeller) tpl:hasConditionPropertyType rdl:RDS361034 ; # ROTATIONAL SPEED tpl:valConditionPropertyValue "1150"^^xsd:decimal ; tpl:hasConditionScale rdl:RDS1342304 ; # REVOLUTION PER MINUTE meta:valEffectiveDate "2021-08-17T16:53:00Z"^^xsd:dateTime . # CL-INDPTY-710.xml # EXAMPLE - Any member of Pump casing class CO_P101-CASE-rev0 # has a Maximum Allowable Pressure @ Pumping Temperature # of 105 BARG @ 20 DEGREE CELSIUS. ex:1247af38-5e33-4e31-a93d-aae56bb41b17 rdf:type tpl:ClassOfIndividualHasConditionalIndirectPropertyWithMaximumValue ; tpl:hasMultidimensionalPropertyType rdl:RDS2225973 ; tpl:hasPossessorType ex:d3bdc308-7179-424c-918f-8c1fd743c970 ; # CO_P101-CASE-rev0 tpl:hasIndirectPropertyType rdl:RDS13113437 ; # UPPER LIMIT ALLOWABLE WORKING PRESSURE tpl:valPropertyValue "105"^^xsd:decimal ; tpl:hasScale rdl:RDS1348874 ; # BARG tpl:hasConditionPropertyType rdl:RDS369674 ; # NORMAL OPERATING TEMPERATURE tpl:valConditionPropertyValue "20"^^xsd:decimal ; tpl:hasConditionScale rdl:RDS1322684 ; # DEGREE CELSIUS meta:valEffectiveDate "2021-08-17T16:53:00Z"^^xsd:dateTime .

#Templates about one or more ClassOfIndividuals, related to: LOCATION

# CL-LOCTN-100.xml # EXAMPLE - Any member of Line Requirements Class CO-RZ17802 # may contain a member of Stream Requirements Class CO-S349 # NOTE - Sometimes it may be empty, and sometime it may contain another stream ex:3dbd5dde-298b-4ec5-b577-6022097ffa2f rdf:type tpl:ClassOfContainmentDefinition ; tpl:hasContainerType ex:862c781c-25a4-4a7b-b66c-554d37e9dd2d ; # Line Requirements Class CO-RZ17802 tpl:hasContainedType ex:fe7f3811-bafb-4330-b901-84092006e6c3 ; # Stream Requirements Class CO-S349 tpl:hasCardinalityOfContainer rdl:RDS222624 ; # ZERO TO ONE tpl:hasCardinalityOfContained rdl:RDS222624 ; # ZERO TO ONE meta:valEffectiveDate "2021-08-19T11:24:00Z"^^xsd:dateTime . # CL-LOCTN-200.xml # EXAMPLE - Member of SAFETY RELIEF VALVE is located above member of VESSEL ex:3dbd5dde-298b-4ec5-b577-6022097ffa2f rdf:type tpl:ClassOfContainmentDefinition ; tpl:hasLocatedType rdl:RDS6330862 ; # SAFETY RELIEF VALVE tpl:hasLocatorType rdl:RDS414674 ; # VESSEL tpl:hasLocationType rdl:RDS2223275 ; # ABOVE tpl:hasCardinalityOfLocated rdl:RDS222624 ; # ZERO TO ONE tpl:hasCardinalityOfLocator rdl:RDS222624 ; # ZERO TO ONE meta:valEffectiveDate "2021-08-19T11:24:00Z"^^xsd:dateTime .

#Templates about one or more ClassOfIndividuals, related to: MATERIAL

# CL-MATL-050.xml # EXAMPLE - Members of CO-P-101 are made of 316SS. ex:a6ff1598-5cb0-4d57-be30-b1c1ea1fc07c rdf:type tpl:SpecializationByMatterType ; tpl:hasSubClass ex:7d978c1e-17f8-411c-9d61-23f718af3b37 ; # CO-P-101 tpl:hasSuperClass rdl:RDS2221635 ; # 316 STAINLESS STEEL meta:valEffectiveDate "2021-08-19T15:38:00Z"^^xsd:dateTime . # CL-MATL-100.xml # EXAMPLE - Members of CO-P-101 are made of 316SS. ex:a6ff1598-5cb0-4d57-be30-b1c1ea1fc07c rdf:type tpl:SpecializationByCompoundType ; tpl:hasSubClass ex:7d978c1e-17f8-411c-9d61-23f718af3b37 ; # CO-P-101 tpl:hasSuperClass rdl:RDS2221635 ; # 316 STAINLESS STEEL meta:valEffectiveDate "2021-08-19T15:38:00Z"^^xsd:dateTime . # CL-MATL-200.xml # EXAMPLE - ASTM A 182/A 182M - F 310 is AUSTENITIC ex:335158d6-3169-4f57-8c8d-05f1f2da0a82 rdf:type tpl:SpecializationByCrystallineStructureType ; tpl:hasSubClass astm:RDS497384 ; # ASTM A 182/A 182M - F 310 tpl:hasSuperClass rdl:RDS2223101 ; # AUSTENITIC meta:valEffectiveDate "2021-08-19T15:47:00Z"^^xsd:dateTime . # CL-MATL-300.xml # EXAMPLE - Stream class CO-S-4783 consists of . ex:f7918f97-e981-4864-a082-1290878e55c2 rdf:type tpl:SpecializationByBiologicalMatterType ; tpl:hasSubClass ex:947fa2e8-9e5c-40d5-9646-cd4a03eb648a ; # CO-S-4783 tpl:hasSuperClass rdl:RDS2227343 ; # BEER meta:valEffectiveDate "2021-08-19T16:36:00Z"^^xsd:dateTime . # CL-MATL-400.xml # EXAMPLE - A POLE is made of PRESSURE IMPREGNATED PINE WOOD ex:b527e35c-b248-4b6c-8189-71d78ba3b3c9 rdf:type tpl:SpecializationByCompositeMaterialType ; tpl:hasSubClass ex:41a86168-ff71-4a08-9f3b-9567e91f616b ; # a Pole tpl:hasSuperClass rdl:RDS7907321 ; # PRESSURE IMPREGNATED PINE WOOD meta:valEffectiveDate "yyyy-mm-ddThh:mm:ss.sZ"^^xsd:dateTime . # CL-MATL-500.xml # EXAMPLE - REACTOR CO-R-120 FILL of CATALYST ex:83631e84-f43a-43e5-929d-499a8855232a rdf:type tpl:SpecializationByParticulateMaterialType ; tpl:hasSubClass ex:d7cf1672-b8b6-48c6-8f97-3951ab5d8509 ; # REACTOR R-120 FILL tpl:hasSuperClass rdl:RDS2225767 ; # CATALYST meta:valEffeciveDate "2021-10-18T10:17:00Z"^^xsd:dateTime . # CL-MATL-600.xml # EXAMPLE - The phase of members of stream class CO-S47 is liquid. ex:2f9e3f2e-c492-467a-a6a9-6b86e280f693 rdf:type tpl:SpecializationByPhase ; tpl:hasSubClass ex:445548d6-044e-40ca-a912-b75328b9e4e8 ; # CO-S47 tpl:hasSuperClass rdl:RDS222609 ; # LIQUID(phase) meta:valEffeciveDate "yyyy-mm-ddThh:mm:ss.sZ"^^xsd:dateTime .

#Templates about one or more ClassOfIndividuals, related to: NUMBER

# CL-NUMB-100.xml # EXAMPLE - The two-dimesnional number [90.8, 4.2] ex:9ff9ed7c-51a0-4565-a27a-848f280620d4 rdf:type tpl:TwoDimensionalNumberDefinition ; tpl:hasDefined ex:e4d0a934-ac2c-4873-b88d-cf52a3ac71f4 ; # [90.8, 4.2] tpl:valFirstNumber "90.8"^^xsd:decimal ; tpl:valSecondNumber "4.2"^^xsd:decimal ; meta:valEffectiveDate "2021-10-22T09:29:00Z"^^xsd:dateTime . # CL-NUMB-200.xml # EXAMPLE - The three-dimensional number [90.8 , 4.2 , 33] ex:f60c907e-4f8d-4de6-9af4-8e3154d32e5d rdf:type tpl:ThreeDimensionalNumberDefinition ; tpl:hasDefined ex:9df0bf39-2bbd-4a15-bb74-cd2e4ed25ff3 ; # [90.8 , 4.2 , 33] tpl:valFirstNumber "90.8"^^xsd:decimal ; tpl:valSecondNumber "4.2"^^xsd:decimal ; tpl:valThirdNumber "33"^^xsd:decimal ; meta:valEffectiveDate "2021-10-22T11:22:00Z"^^xsd:dateTime . # CL-NUMB-300.xml # EXAMPLE - The number range [-273.15 - +*] ex:95fd54e6-cb33-403d-acea-28147f38c418 rdf:type tpl:NumberRangeDefinition ; tpl:hasNumberRange rdl:RDS2229877 ; # NUMBER RANGE OF -273.15 TO INF tpl:valLowerBound "-273.15"^^xsd:decimal ; tpl:valUpperBound "+*"^^xsd:decimal ; meta:valEffectiveDate "2021-10-22T12:16:00Z"^^xsd:dateTime . # CL-NUMB-400.xml # EXAMPLE - The number space of the coordinate triples of the maintenance envelop of E-101 in a plant # is bounded by the number space of the coordinate triples of an adjacent wall ex:2e82364c-7401-47d4-862a-5b4675771ee8 rdf:type tpl:NumberSpaceWithBoundingNumberSpace ; tpl:hasNumberSpace ex:767c10f4-7951-4f43-a95f-88f0577a106c ; # number space of the coordinate triples of the maintenance envelop of E-101 tpl:hasBoundingSpace ex:d6bc05b7-02fc-4540-be30-02a90392499f ; # number space of the coordinate triples of an adjacent wall meta:valEffectiveDate "2021-10-22T13:35:00Z"^^xsd:dateTime .

#Templates about one or more ClassOfIndividuals, related to: OTHER RELATIONSHIP

# CL-OTHRL-250.xml # EXAMPLE - The ClassOfRelationshipWithSignature IS MANUFACTURED BY # is defined by the ClassOfActivity MANUFACTURING, # with the ParticipatingRoleAndDomain ARTEFACT in the Role of PRODUCT, # and the ParticipatingRoleAndDomain MANUFACTURER in the Role of PERFORMER. ex:7256a059-172e-41fb-8991-68b512763649 rdf:type tpl:ClassOfOtherRelationshipWithDualParticipation ; tpl:hasDefined rdl:RDS2229929 ; # IS MANUFACTURED BY tpl:hasActivityType rdl:RDS9661877; # MANUFACTURING tpl:hasParticipantType1 rdl:RDS422594 ; # ARTEFACT tpl:hasRoleOfParticipant1 rdl:RDS13875454 ; # PRODUCT tpl:hasCardinalityOfParticipant1 rdl:RDS999900701 ; # ONE TO MANY tpl:hasParticipantType2 rdl:RDS4242650 ; # MANUFACTURER tpl:hasRoleOfParticipant2 rdl:RDS222365 ; # PERFORMER tpl:hasCardinalityOfParticipant2 rdl:RDS999900701 ; # ONE TO MANY meta:valEffetiveDate "2021-12-03T13:02:00Z"^^xsd:dateTime . # CL-OTHRL-500.xml # EXAMPLE - In Process Design a Stream Class S46 # has the instance of ClassOfActivity, called Unit Operation UO37, as destination. ex:6d721d45-cbad-4fe6-ab93-8e3b14f2704e rdf:type tpl:ClassOfOtherRelationshipWithParticipationAndInvolvementByReference ; tpl:hasDefined rdl:RDS2228129 ; # IS DESTINATION OF tpl:hasActivityType rdl:RDS2229988 ; # STREAMING tpl:hasParticipantType ex:f638b5e1-c576-4ef8-8a50-62249dd9fadc ; # LIQUID STREAM S46 tpl:hasRoleOfParticipant rdl:RDS222362 ; # SUBJECT tpl:hasCardinalityOfParticipant rdl:RDS999900701 ; # ONE TO MANY tpl:hasReferenceType ex:746a4399-c921-489e-bdeb-950efabbd872 ; # UNIT OPERATION UO37 tpl:hasRoleOfReference rdl:RDS13421040 ; # DESTINATION tpl:hasCardinalityOfReference rdl:RDS999900701 ; # ONE TO MANY meta:valEffetiveDate "2021-12-03T13:02:00Z"^^xsd:dateTime .

#Templates about one or more ClassOfIndividuals, related to: PROPERTY and STATUS

# CL-PTYST-160.xml # EXAMPLE - Members of Requirements class CO-RZ17801 for line RZ17801 # have a status "STRESS RISK LEVEL - HIGH". ex:b02c6fe5-49a2-426f-a799-fbe668e1292f rdf:type tpl:ClassOfIndividualHasStatus ; tpl:hasPossessorType ex:3f02b528-b770-4aa8-bc88-245a34a4bee2 ; # CO-RZ17801 tpl:hasStatus rdl:RDS2223920 ; # STRESS RISK LEVEL - HIGH meta:valEffectiveDate "2021-11-02T11:10:00Z"^^xsd:dateTime . # CL-PTYST-170.xml # EXAMPLE - Members of document type "PIPING ISOMETRIC DRAWING" # shall have a status "AFC" before the "START OF FABRICATION" (part of CFIHOS data model) ex:15afacee-ede5-46b1-9202-f0e32511514f rdf:type tpl:ClassOfIndividualHasStatusBeforeClassOfEvent ; tpl:hasPossessorType rdl:RDS331559 ; # PIPING ISOMETRIC DRAWING tpl:hasStatus rdl:RDS2225671 ; # AFC (Approved For Construction) tpl:hasEventType rdl:RDS2227185 ; # START OF FABRICATION meta:valEffectiveDate "2021-11-02T11:28:00Z"^^xsd:dateTime . # CL-PTYST-200.xml # EXAMPLE - Members of design class CO-P-101 have an estimated mass of 240 kg. ex:f774cda9-298c-4cb5-b67a-c72202a8eec7 rdf:type tpl:ClassOfIndividualHasPropertyWithValueAndStatus ; tpl:hasPossessorType ex:865e7acd-6282-47dd-866d-ca2c9ac54694 ; tpl:hasPropertyType rdl:RDS2220062 ; # LENGTH OVERALL (LOA) tpl:valPropertyValue "240"^^xsd:decimal ; tpl:hasScale rdl:RDS1328669 ; # KILOGRAM tpl:hasPropertyStatus rdl:RDS2220182 ; # ESTIMATED meta:valEffectiveDate "2022-11-02T11:45:00Z"^^xsd:dateTime . # CL-PTYST-240.xml # EXAMPLE - Members of Offshore Vessel Type Skandi # have an LOA (Length Overall) of 157 m. ex:f4612553-3f42-4e2d-93c6-8527cd21f805 rdf:type tpl:ClassOfIndividualHasPropertyWithValue ; tpl:hasPossessorType ex:R983923 ; # Offshore Vessel Type Skandi (fake id) tpl:hasPropertyType rdl:RDS2220062 ; # LENGTH OVERALL (LOA) tpl:valPropertyValue "157"^^xsd:decimal ; tpl:hasScale rdl:RDS1332674 ; # METRE meta:valEffectiveDate "2021-11-02T11:45:00Z"^^xsd:dateTime . # CL-PTYST-260.xml # EXAMPLE - Members of Vessel (class) CO_V-102 # have a net selling price of 30,590 USD. ex:4f7e35bd-9402-4b65-9a01-cdb1da1ebca4 rdf:type tpl:ClassOfIndividualHasMonetaryValue ; tpl:hasPossessorType ex:e99229d2-480a-43fd-a863-c3c7ce8cb38e ; # Vessel Requirements Class CO_V-102 tpl:hasMonetaryValueType rdl:RDS2229260 ; # NET SALES PRICE tpl:valMonetaryValue "30590"^^xsd:decimal ; tpl:hasCurrency rdl:RDS2228349 ; # USD meta:valEffectiveDate "2021-10-24T10:49:00Z"^^xsd:dateTime . # CL-PTYST-400.xml # EXAMPLE - Members of ClassOfInanimatePhysicalObject 'CO-P-101' weigh 240kg +90g -50g ex:26d5225d-eb01-4b41-bdb6-e2d4454a2876 rdf:type tpl:ClassOfIndividualHasPropertyWithVariance ; tpl:hasPossessorType ex:f0266268-567e-4a76-a676-21eed8c50f57 ; # requirements class CO-P-101 tpl:hasPropertyType rdl:RDS353339 ; # MASS tpl:valPropertyValue "240"^^xsd:decimal ; tpl:hasScale rdl:RDS1328669 ; # KILOGRAM tpl:valPositiveVariance "90"^^xsd:decimal ; tpl:valNegativeVariance "50"^^xsd:decimal ; tpl:hasVarianceScale rdl:RDS1325789 ; # GRAM meta:valEffectiveDate "2021-11-02T12:21:00Z"^^xsd:dateTime . # CL-PTYST-480.xml # EXAMPLE - Members of ClassOfInanimatePhysicalObject 'CO-P-101' weigh 240kg +0.12% -0.066%. ex:26d5225d-eb01-4b41-bdb6-e2d4454a2876 rdf:type tpl:ClassOfIndividualHasPropertyWithPercentageVariance ; tpl:hasPossessorType ex:f0266268-567e-4a76-a676-21eed8c50f57 ; # requirements class CO-P-101 tpl:hasPropertyType rdl:RDS353339 ; # MASS tpl:valPropertyValue "240"^^xsd:decimal ; tpl:hasScale rdl:RDS1328669 ; # KILOGRAM tpl:valPositiveVariance "0.12"^^xsd:decimal ; tpl:valNegativeVariance "0.066"^^xsd:decimal ; meta:valEffectiveDate "2021-11-02T12:21:00Z"^^xsd:dateTime . # CL-PTYST-560.xml # EXAMPLE - Members of requirements class CO-P-101 of pump P-101, with variable drive unit, # shall have a capacity in terms of volume flow rate of 250 gpm # at a rotational speed of the impeller of 1750 rpm. ex:d4064388-0fd5-4622-ac88-315e23f2dc54 rdf:type tpl:ClassOfIndividualHasConditionalPropertyWithValue ; tpl:hasMultidimensionalPropertyType rdl:RDS2225972 ; # PUMP CAPACITY(volume flow rate) AT IMPELLER SPEED tpl:hasPossessorType ex:f0266268-567e-4a76-a676-21eed8c50f57 ; # requirements class CO-P-101 tpl:hasPropertyType rdl:RDS7354248 ; # CAPACITY(volume flow rate) tpl:valPropertyValue "250"^^xsd:decimal ; tpl:hasScale rdl:RDS1346759 ; # US GALLON PER MINUTE tpl:hasConditionPossessorType ex:f8af70b7-dc1a-4265-8da3-64a6ddaa9ebe ; # requirements class for Impeller CO-P-101-IMP tpl:hasConditionPropertyType rdl:RDS361034 ; # ROTATIONAL SPEED tpl:valConditionPropertyValue "1750"^^xsd:decimal ; tpl:hasConditionScale rdl:RDS1342304 ; # REVOLUTION PER MINUTE meta:valEffectiveDate "2021-11-02T12:42:00Z"^^xsd:dateTime . # CL-PTYST-640.xml # EXAMPLE - Any member of Stream class CO-S-34 # has a vapour pressure of 2.3 kPa # at a temperature of 20 degrees Celsius. ex:fca24f8a-844c-4337-80d3-c368da8aa3fd rdf:type tpl:ClassOfIndividualHasTwoDimensionalPropertyWithValues ; tpl:hasMultidimensionalPropertyType rdl:RDS7345705 ; # VAPOUR PRESSURE AT OPERATING TEMPERATURE tpl:hasPossessorType ex:69e7d04e-eaff-4f39-8d42-c68792cc71e1 ; # Stream class CO-S-34 tpl:hasPropertyType1 rdl:RDS358739 ; # VAPOUR PRESSURE tpl:valPropertyValue1 "2.3"^^xsd:decimal ; tpl:hasScale1 rdl:RDS2227188 ; # KILOPASCAL ABSOLUTE tpl:hasPropertyType2 rdl:RDS357119 ; # OPERATING TEMPERATURE tpl:valPropertyValue2 "20"^^xsd:decimal ; tpl:hasScale2 rdl:RDS1322684 ; # DEGREE CELSIUS meta:valEffectiveDate "2021-11-02T14:54:00Z"^^xsd:dateTime . # CL-PTYST-680.xml # EXAMPLE - The differential pressure between inlet and outlet of any member of pump class B14-S-P101 # is 3.27 BAR GAUGE. ex:77a2c0fa-5b1c-4f80-ab0a-e30a13b5d2fd rdf:type tpl:PropertyDifferenceBetweenTwoInstancesOfClassOfIndividual ; tpl:hasHighPossessorType ex:f229fd7c-ae2c-4bce-9c26-d60da5b510b8 ; # B14-S-P101-OUT tpl:hasLowPossessorType ex:68fe7434-d73d-44e6-8bd4-5afa8b75cf46 ; # B14-S-P101-IN tpl:hasPropertyType rdl:RDS361574 ; # DIFFERENTIAL PRESSURE tpl:valDifferentialValue "3.27"^^xsd:decimal ; tpl:hasScale rdl:RDS1348874 ; # BAR GAUGE meta:valEffectiveDate "2024-02-29T16:00:00Z"^^xsd:dateTime . # CL-PTYST-720.xml # EXAMPLE - Members of requirements class CO-P-101 of pump P-101 # have been designed for a duty cycle of 0.82 ex:e7db89f6-77dd-4108-a292-2c9f9eecfef6 rdf:type tpl:ClassOfIndividualHasPropertyRatio ; tpl:hasMultidimensionalPropertyType rdl:RDS2227189 ; # DUTY CYCLE tpl:hasPossessorType ex:f0266268-567e-4a76-a676-21eed8c50f57 ; # requirements class CO-P-101 tpl:hasPropertyType rdl:RDS356039 ; # TIME tpl:valPropertyValue1 "60"^^xsd:decimal ; tpl:valPropertyValue2 "73"^^xsd:decimal ; tpl:valPropertyRatio "0.82"^^xsd:decimal ; tpl:hasScale rdl:RDS1326734 ; # HOUR meta:valEffectiveDate "2021-11-02T15:11:00Z"^^xsd:dateTime . # CL-PTYST-740.xml # EXAMPLE - Any member of Property Range rdl:RDS627081371 (4 - 20 MILLIAMPERE DC) # have a DIRECT CURRENT (DC) range # with a Lower Bound of4 mADC # and an Upper Bound of 20 mADC ex:a579dea9-abdf-45e8-a49c-dc787e760d8f rdf:type tpl:PropertyRangeDefinition ; tpl:hasPropertyRange rdl:RDS627081371 ; tpl:hasPropertyType rdl:RDS2224478 ; # DIRECT CURRENT (DC) tpl:valLowerBound "4"^^xsd:decimal ; tpl:valUpperBound "20"^^xsd:decimal ; tpl:hasScale rdl:RDS2229342 ; # MILLIAMPERE DC meta:valEffectiveDate "2021-10-22T13:49:00Z"^^xsd:dateTime . # CL-PTYST-760.xml # EXAMPLE - Any member of Requirements Class CO-P101-CASING # has a SURFACE TEMPERATURE range of 600 - 2000 K ex:b271b532-9c86-4cd8-8e4b-577571cea4db rdf:type tpl:ClassOfIndividualHasPropertyRangeWithValues ; tpl:hasPossessorType ex:f51963c6-449f-4852-aeae-5fa5c8543412 ; # CO-P101-CASING tpl:hasPropertyType rdl:RDS2229343 ; # SURFACE TEMPERATURE tpl:valLowerBound "600"^^xsd:decimal ; tpl:valUpperBound "2000"^^xsd:decimal ; tpl:hasScale rdl:RDS1327904 ; # KELVIN meta:valEffectiveDate "2021-10-22T16:58:00Z"^^xsd:dateTime . # CL-PTYST-800.xml # EXAMPLE - Definition of a temperature of 100 degrees Celsius. # NOTE - Only to be used for repertitive occurring Properties ex:2ec8dd21-185b-4bbf-ae50-1649a0781a2d rdf:type tpl:PropertyDefinition ; tpl:hasDefined rdl:RDS2227190 ; # TEMPERATURE OF 100 DEGREE CELSIUS tpl:hasPropertyType rdl:RDS355859 ; # TEMPERATURE tpl:valPropertyValue "100"^^xsd:decimal ; tpl:hasScale rdl:RDS1322684 ; # DEGREE CELSIUS meta:valEffectiveDate "2021-11-02T15:52:00Z"^^xsd:dateTime .

#Templates about one or more ClassOfIndividuals, related to: SET OPERATIONS

# CL-SETOP-080.xml # EXAMPLE - The difference between a Class with members {A, B, C} # and a Class with members {B, C, D} # is a Class with members {A, D} . ex:9c6c120a-7838-4126-946a-64011ae6513d rdf:type tpl:DifferenceOf2Classes ; tpl:hasClass1 ex:a832747b-f548-4c0f-b7ed-5c87a38dade2 ; # {A, B, C} tpl:hasClass2 ex:e46eb77e-4a7b-4203-a45f-e5f86804b95a ; # {B, C, D} tpl:hasClassDifference ex:2221961d-ddbc-4153-8bf2-d021dc1e244d ; # {A, D} meta:valEffectiveDate "2021-12-04T15:06:00Z"^^xsd:dateTime . # CL-SETOP-120.xml # EXAMPLE - FLOW TRANSMITTER rdl:RDS880154 # is equivalent to cfihos:30000643 flow transmitter in the CFIHOS RDL # NOTE - They have the same members ex:e0cc0b56-b3f2-4b7f-ae56-5a88dee5d515 rdf:type tpl:EquivalentClasses ; tpl:hasClass1 rdl:RDS880154 ; tpl:hasClass2 cfihos:30000643 ; meta:valEffectiveDate "2021-12-04T15:06:00Z"^^xsd:dateTime . # CL-SETOP-160.xml # EXAMPLE - Effective documents X-rev1 and X-rev2 are disjoint ex:af02e851-c9d0-4fed-9229-0fa9a93ad779 rdf:type tpl:DisjointnessOf2Classes ; tpl:hasClass1 ex:3f38ecc4-6366-441f-be9b-44f49ae0cbfb ; # Document X-rev1 tpl:hasClass2 ex:ea1e8f53-b30c-45b7-b4ae-c63bd6a4b9ce ; # Document X-rev2 meta:valEffectiveDate "2021-12-04T15:27:00Z"^^xsd:dateTime . # CL-SETOP-400.xml # EXAMPLE - Data elements A and B are the result of the intersection between # Specification XYZ rev.1 with data elements A, B, C, and # Specification XYZ rev.2 with # data elements A, B, D . ex:4fdd6e4e-5468-424e-846e-83cfa665b800 rdf:type tpl:IntersectionOf2Classes ; tpl:hasClass1 ex:b7372aac-a7f3-4142-8b28-f2b997499264 ; # Specification XYZ rev.1 with data elements A, B, C tpl:hasClass2 ex:85750af6-cb78-4017-9113-4c5ad5d84077 ; # Specification XYZ rev.2 with data elements A, B, D tpl:hasClassIntersection ex:35758aa8-1673-4ba7-a8aa-cac0996371c3 ; # Data elements A,B meta:valEffectiveDate "2021-12-10T12:48:00Z"^^xsd:dateTime . # CL-SETOP-480.xml # EXAMPLE - Let C be a Pipe Class that allows the use of P and Q, so C = {P,Q}; # Let N be a Piping Network that must be a member of C, but requires the use of Q and R, so N = {Q,R}, # then the relative complement of C in N is R: NC = {R}. # In other words: R is required in the Piping Network N but is not (yet) part of the applicable Pipe Class C. ex:2e0d651c-bcad-41ee-b128-8b8ef04193cb rdf:type tpl:RelativeComplementOf2Classes ; tpl:hasClass1 ex:b7c376c6-6750-41ea-8bb0-61c320c7e3e6 ; # C = {P,Q} tpl:hasClass2 ex:9f6a9b6b-48c5-4163-8875-8a1716dbd270 ; # N = {Q,R} tpl:hasRelativeComplement ex:53881d08-d989-41b5-8193-48a389cb7e94 ; # R meta:valEffectiveDate "2021-12-10T14:21:00Z"^^xsd:dateTime . # CL-SETOP-560.xml # EXAMPLE - The union of C1={A,B,C} and C2={B,C,D} results in C3={A,B,C,D}, # where A, B, C, and D are members of Part 2 Classes C1, C2, and/or C3 and doubles are omitted. ex:8ebcda08-f108-4687-8dec-744d833fb0de rdf:type tpl:UnionOf2Classes ; tpl:hasClass1 ex:d039e10d-f006-44fc-86c0-087f4b8b1d4c ; # C1={A,B,C} tpl:hasClass2 ex:f5ad52a9-aa0e-458c-bc41-c85f39ca99cf ; # C2={B,C,D} tpl:hasClassUnion ex:2d3df8a6-5900-4c7a-9cf2-8faa98b23b9b ; # C3={A,B,C,D} meta:valEffectiveDate "2021-12-10T14:37:00Z"^^xsd:dateTime . # CL-SETOP-640.xml # EXAMPLE - A pick-list of acceptable instances for the data element ''Lubrication" in the API 610 pump data sheet ex:9000a813-ecb9-4ef6-81dc-507c48193a53 rdf:type tpl:EnumerationOfClass ; tpl:hasSet ex:ceae7464-d343-4917-a4ad-9b1d2c24aa05 ; # the collection of Class instances for "Lubricator" on API 610 datasheet tpl:hasMember rdl:RDS5995396 ; # OIL MIST LUBRICATOR meta:valEffectiveDate "2021-09-21T12:48:00Z"^^xsd:dateTime . # CL-SETOP-880.xml # EXAMPLE - Template instances {A,B,C} and {B,C,D}, as members of an instance of EnumeratedSetOfClass 'Datasheet GHJ-254 data', # have {B,C} as results of the intersection. ex:24076210-a1ac-4778-bde1-08b6d0b20f81 rdf:type tpl:IntersectionOfEnumeratedSetOfClass ; tpl:hasInput ex:6ba8ea94-7d62-4b68-9a90-d34cd8178b17; # EnumeratedSetOfClass 'Datasheet GHJ-254 data' tpl:hasResult ex:e63b2a37-6d61-4ef3-b186-d312cfc26d3b ; # {B,C} meta:valEffectiveDate "2021-12-10T15:07:00Z"^^xsd:dateTime . # CL-SETOP-900.xml # EXAMPLE - Template instances {A,B,C} and {B,C,D}, as members of an instance of EnumeratedSetOfClass 'Datasheet GHJ-254 data', # are unionized to {A,B,C,D} ex:24076210-a1ac-4778-bde1-08b6d0b20f81 rdf:type tpl:UnionOfEnumeratedSetOfClass ; tpl:hasInput ex:6ba8ea94-7d62-4b68-9a90-d34cd8178b17; # EnumeratedSetOfClass 'Datasheet GHJ-254 data' tpl:hasResult ex:e63b2a37-6d61-4ef3-b186-d312cfc26d3b ; # {A,B,C,D,E,F} meta:valEffectiveDate "2021-12-10T15:07:00Z"^^xsd:dateTime .

#Templates about one or more ClassOfIndividuals, related to: SHAPE CLASS

# CL-SHAPE-200.xml # EXAMPLE - mySphere has a diameter range with a value between 5 and 10 m. ex:dac0f750-81d0-4c72-98c2-fb6c882a4de1 rdf:type tpl:ClassOfShapeDimensionDefinition ; tpl:hasShapeType ex:89c1d36b-1b2e-4066-9159-a5952ded6ae3 ; # mySphere tpl:hasShapeDimension rdl:RDS350954 ; # DIAMETER tpl:hasPropertySpace exrdl:R453873 ; # A length range of 5 - 10 m in local RDL extension meta:valEffectiveDate "2021-12-10T15:48:00Z"^^xsd:dateTime . # CL-SHAPE-300.xml # EXAMPLE -Any member of Tank class CO-T-101 has the shape of a sphere with a diameter of 10 m ex:de459ce6-0225-4679-a780-7a303c42859d rdf:type tpl:ShapeDimensionOfClassOfShapeWithReferenceProperty ; tpl:hasPossessorType ex:8a38285a-1b8d-4c76-9211-3b1a66a6a54d ; # Tank requirements class CO-T-101 tpl:hasShapeType rdl:RDS2225772 ; # SPHERE(shape) tpl:hasShapeDimension rdl:RDS350954 ; # DIAMETER tpl:hasProperty exrdl:R453868 ; # A length of 10 m in local RDL extension meta:valEffectiveDate "2021-12-10T16:04:00Z"^^xsd:dateTime . # CL-SHAPE-400.xml # EXAMPLE - Any member of the shape of a Circular Flat Washer, defined in ISO 15926 Part 3, # that complies with exrdl:R47372, a user-defined as P3 Circular Flatwasher as an XML Literal in XML. ex:215652c5-0fb9-4c5e-add8-94e3d18c4582 rdf:type tpl:DefinitionOfShapeRepresentation ; tpl:hasShape ex:fa54ec70-0b78-4c1f-bfd9-eb458860eb81 ; # the ID of the declared Shape tpl:hasRepresentation "(ISO 15926-3 code)" ; tpl:hasRepresentationType exrdl:R47372 ; # user-defined requirements meta:valEffectiveDate "2022-11-18T14:37:00Z"^^xsd:dateTime . # CL-SHAPE-500.xml # EXAMPLE - Members of Offshore Vessel Type Skandi # have an LOA (Length Overall) of 157 m ex:601e09f4-9854-4567-8a66-21f81e4c7e72 rdf:type tpl:ClassOfIndividualHasDimensionedShapeWithValue ; tpl:hasPossessorType ex:ea7cf639-41a7-47e4-9fd5-c3c8879ca078 ; # requirements class of Skandi (offshore vessel) tpl:hasShapeType rdl:RDS290699 ; # HULL tpl:hasDimensionType rdl:RDS2220062 ; # LENGTH OVERALL (LOA) tpl:valPropertyValue "157"^^xsd:decimal ; tpl:hasScale rdl:RDS1332674 ; # METRE meta:valEffectiveDate "2021-12-10T16:23:00Z"^^xsd:dateTime .

#Templates about one or more ClassOfIndividuals, related to: STRUCTURE

# CL-STRUC-060.xml # EXAMPLE - Fluid A is a component of Fluid Mixture M. # The latter can have zero to infinite components. ex:5e016a45-5a19-43a8-a116-562d77c4ac7b rdf:type tpl:ClassOfCompositionDefinition ; tpl:hasClassOfWhole ex:19386c33-76ca-48e3-bb35-9fcbc0740394 ; # Fluid Mixture M tpl:hasClassOfPart ex:e8637f78-a228-4ec9-97f7-b4bd6e31837d ; # Fluid A tpl:hasDefined ex:7a4d93ec-aaf1-4d1d-8a74-453927cde167 ; # auto-generated, for use in templates at Individual level tpl:hasCardinalityOfWhole rdl:RDS222625 ; # ONE TO ONE tpl:hasCardinalityOfPart rdl:RDS999900701 ; # ONE TO MANY meta:valEffectiveDate "2021-12-12T11:35:00Z"^^xsd:dateTime . # CL-STRUC-080.xml # EXAMPLE - The concentration of dissolved salts in seawater (its salinity) is about 3.5% of the weight of seawater. ex:686e8607-1bf9-4ba4-92a4-9ea4d90b632c rdf:type tpl:ClassOfCompositionPartPercentage ; tpl:hasClassOfWhole rdl:RDS890774 ; # SEAWATER tpl:hasClassOfPart rdl:RDS8015624941 ; # SALT tpl:hasPercentageType rdl:RDS16430480 ; # WEIGHT PERCENTAGE tpl:valPartPercentageValue "3.5"^^xsd:decimal ; meta:valEffectiveDate "2021-10-14T11:21:00Z"^^xsd:dateTime . # CL-STRUC-081.xml # EXAMPLE - Members of our crude oil class do not contain more than 0.5 - 1% of water. ex:c17a1ccc-0b42-4979-b712-189e371a4de2 rdf:type tpl:ClassOfCompositionPartPercentageByRange ; tpl:hasClassOFWhole exrdl:R58382 ; # locally defined Crude Oil class tpl:hasClassOfPart rdl:RDS1012769 ; # WATER tpl:hasPercentageType rdl:RDS16430750 ; # VOLUME PERCENTAGE tpl:hasPartPercentageRange ex:R4383409 ; # 0.5 - 1.0 Vol% (defined in local RDL extension) meta:valEffectiveDate "2021-10-14T12:56:00Z"^^xsd:dateTime . # CL-STRUC-120.xml # EXAMPLE - Requirements vessel class CO-V-101 # has requirements insulation class CO-V-101-INS as a part in an arrangement. ex:6c6bdd97-d5e1-4844-892b-ff1ebd873b64 rdf:type tpl:ClassOfArrangementDefinition ; tpl:hasClassOfWhole ex:e285f08c-f172-4b73-b0d0-56cc89abfd96 ; # Requirements class CO-V-101 tpl:hasClassOfPart ex:8a436139-e2e7-481d-9eff-74889e7d46b7 ; # CO-V-101-INS tpl:hasDefined ex:7a4d93ec-aaf1-4d1d-8a74-453927cde167 ; # for classification of ArrangementOfIndividual relationship tpl:hasCardinalityOfWhole rdl:RDS222625 ; # ONE TO ONE tpl:hasCardinalityOfPart rdl:RDS222625 ; # ONE TO ONE meta:valEffectiveDate "2021-12-12T11:35:00Z"^^xsd:dateTime . # CL-STRUC-180.xml # EXAMPLE - One to many Condensate Regeneration Systems may have zero to many Pumps as a part. ex:9fc22f6a-93f4-4187-897d-766569d08d87 rdf:type tpl:ClassOfAssemblyDefinition ; tpl:hasClassOfWhole rdl:RDS276254 ; # CONDENSATE REGENERATION SYSTEM tpl:hasClassOfPart rdl:RDS327239 ; # PUMP tpl:hasDefined ex:1692afae-275d-4d7b-93c0-6d6fce30a6b6 ; # for classification of AssemblyOfIndividual tpl:hasCardinalityOfWhole rdl:RDS999900701 ; # ONE TO MANY tpl:hasCardinalityOfPart rdl:RDS999900700 ; # ZERO TO MANY meta:valEffectiveDate "2021-12-13T11:18:00Z"^^xsd:dateTime . # CL-STRUC-240.xml # EXAMPLE - Members of BLOCK VALVE class do not have a CONTROLLED ACTUATOR. ex:57d9f374-0feb-497b-8ab7-2bf57174b75f rdf:type tpl:PartInClassOfAssemblyApplicableYesNo ; tpl:hasClassOfWhole rdl:RDS280979 ; # BLOCK VALVE tpl:hasClassOfPart rdl:RDS2220505 ; # CONTROLLED ACTUATOR tpl:valApplicableYesNo "false"^^xsd:boolean ; meta:valEffectiveDate "2021-12-13T14:07:00Z"^^xsd:dateTime . # CL-STRUC-300.xml # EXAMPLE - Members of RAISED FACE FLANGE have a member of RAISED FACE as a Feature. ex:f047ae8f-a0d3-4859-9995-722d7f90d2a4 rdf:type tpl:ClassOfFeatureWholePartDefinition; tpl:hasClassOfWhole rdl:RDS957284 ; # RAISED FACE FLANGE tpl:hasClassOfPart rdl:RDS2225586 ; # RAISED FACE tpl:hasDefined ex:5e47cf8c-cc06-44e6-90c6-270a240a8248 ; # for classification of FeatureWholePart tpl:hasCardinalityOfWhole rdl:RDS222625 ; # ONE TO ONE tpl:hasCardinalityOfPart rdl:RDS222625 ; # ONE TO ONE meta:valEffectiveDate "2021-12-13T14:07:00Z"^^xsd:dateTime . # CL-STRUC-480.xml # EXAMPLE - Line section requirements class CO-RZ79801-S4 # has a flanged connection # with the inlet nozzle requirements class CO-P101-IN ex:d6341709-2760-49f7-b638-6b540a77b315 rdf:type tpl:ClassOfDirectConnectionDefinition ; tpl:hasClassOfSide1 ex:bd7d0bd9-af65-4f34-ad3e-531b7e3dc65d ; # CO-RZ79801-S4 tpl:hasClassOfSide2 ex:916484e2-ffb1-4eb8-9016-31d435e13662 ; # CO-P101-IN tpl:hasConnectionType rdl:RDS2229203 ; # FLANGED CONNECTION tpl:hasDefined ex:c9f275c1-bd64-4fad-aabb-b83bc7ba0ac5 ; # for classification of a DirectConnection tpl:hasCardinalityOfSide1 rdl:RDS222624 ; # ZERO TO ONE tpl:hasCardinalityOfSide2 rdl:RDS222624 ; # ZERO TO ONE meta:valEffectiveDate "2021-12-14T12:26:00Z"^^xsd:dateTime . # CL-STRUC-600.xml # EXAMPLE - Members of Pump requirements class CO-P-101 # are indirectly (via a gearbox) connected with # members of its driver requirements class CO-PM-101. ex:e62ba368-cdc0-4bb0-a03f-515e53887c30 rdf:type tpl:ClassOfIndirectConnectionDefinition ; tpl:hasClassOfSide1 ex:da946b96-4760-45cf-ad3f-4917cd34f8f9 ; # CO-P-101 tpl:hasClassOfSide2 ex:102d9695-e923-4f5b-9249-4a22e7f391ce ; # CO-PM-101 tpl:hasConnectionType rdl:RDS2229202 ; # DRIVE-TO-DRIVEN CONNECTION tpl:hasDefined ex:59772199-d854-40b5-8cf1-bf50ba6a5409 ; # for use in template ClassOfIndividualUsedInIndirectConnectionDefinition tpl:hasCardinalityOfSide1 rdl:RDS222624 ; # ZERO TO ONE tpl:hasCardinalityOfSide2 rdl:RDS222624 ; # ZERO TO ONE meta:valEffectiveDate "2021-12-14T13:36:00Z"^^xsd:dateTime . # CL-STRUC-660.xml # EXAMPLE - A Ring Joint gasket is used for the direct connection between two RTJ Flanges ex:937c4439-03cb-423d-a783-669788991d0c rdf:type tpl:ClassOfIndividualUsedInDirectConnectionDefinition ; tpl:hasClassOfUsed rdl:RDS473084 ; # RING JOINT GASKET tpl:hasConnection ex:c9f275c1-bd64-4fad-aabb-b83bc7ba0ac5 ; # declared in another template tpl:hasCardinalityOfUsed rdl:RDS222624 ; # ZERO TO ONE tpl:hasCardinalityOfConnection rdl:RDS222624 ; # ZERO TO ONE meta:valEffectiveDate "2021-12-13T14:40:00Z"^^xsd:dateTime . # CL-STRUC-720.xml # EXAMPLE - Members of Line class CO-FX-2487 # are used for the indirect connection between # members of the Crude Unit CO-C-302 and # members of the Distillate Hydrotreater CO-C-303 ex:7b97451c-33f3-472a-a47d-d1a70c164751 rdf:type tpl:ClassOfIndividualUsedInIndirectConnectionDefinition ; tpl:hasClassOfUsed ex:edae4839-e1cf-499f-89ba-19acc944455c ; # CO-FX-2487 tpl:hasConnection ex:ccab72e3-150e-41f6-9dc8-77b45c5e8759 ; # defined with ClassifiedClassOfIndirectConnectionDefinition tpl:hasCardinalityOfUsed rdl: ; # ONE TO ONE tpl:hasCardinalityOfConnection rdl: ; # ONE TO ONE meta:valEffectiveDate "2021-12-14T14:53:00Z"^^xsd:dateTime . # CL-STRUC-780.xml # EXAMPLE - A BOX class of which the members have 100 HEAVY HEX BOLT ASME B18.2.1 NS 2 bolts ex:2dcdf281-cf26-42f7-a528-2c52d348d60a rdf:type tpl:NumberOfMembersOfClassOfIndividual ; tpl:hasAggregateType exrdl:B123456 ; tpl:hasCollectorType rdl:RDS2227954 ; # BOX tpl:hasObjectType asme:RDS847394 ; # HEAVY HEX BOLT ASME B18.2.1 NS 2 tpl:hasAggregateCount "100"^^xsd:nonNegativeInteger ; meta:valEffectiveDate "2021-12-14T16:11:00Z"^^xsd:dateTime .


Templates about one or more PossibleIndividuals, related to:

  • ACTIVITY
  • CLASSIFICATION
  • DESCRIPTION
  • DOCUMENT
  • EXISTENCE
  • FUNCTION
  • IDENTIFICATION
  • LOCATION
  • MATERIAL
  • PROPERTY-INDIRECT
  • PROPERTY and STATUS
  • RELATIONSHIP-OTHER
  • SHAPE
  • STREAM
  • STRUCTURE

    #Templates about one or more PossibleIndividuals, related to: ACTIVITY

    # IN-ACTIV-020.xml # EXAMPLE - Pump P-101/AN4582483 # participates in the Activiy A457438 (declared as PUMPING) # in the Role of PERFORMER. # NOTE - Pump P-101/AN4582483 is the tagnumber of the implemention of P-101 with asset numbered AN4582483) ex:605753d4-9218-4f29-a102-d44b43babb78 rdf:type tpl:ParticipationOfPhysicalObjectInActivity ; tpl:hasActivity ex:b19c7864-7cff-494b-8bcb-c49246302dfb ; # A457438 tpl:hasParticipant ex:43974c9d-610d-4fc6-8ac9-26216cbc0652 ; # P-101/AN4582483 tpl:hasParticipantRole rdl:RDS222365 ; # PERFORMER meta:valEffectiveDate "2022-09-21T18:44:00Z"^^xsd:dateTime . # IN-ACTIV-040.xml # EXAMPLE - Pump P-101/AN4582483 # has begun to participate in the Activiy A457438 (declared as PUMPING) # in the Role of PERFORMER # on 2021-09-21T18:44:00Z # NOTE - Pump P-101/AN4582483 is the tagnumber of the implemention of P-101 with asset numbered AN4582483) ex:605753d4-9218-4f29-a102-d44b43babb78 rdf:type tpl:BegunParticipationOfPhysicalObjectInActivity ; tpl:hasActivity ex:b19c7864-7cff-494b-8bcb-c49246302dfb ; # A457438 tpl:hasParticipant ex:43974c9d-610d-4fc6-8ac9-26216cbc0652 ; # P-101/AN4582483 tpl:hasParticipantRole rdl:RDS222365 ; # PERFORMER tpl:valStartDate "2021-09-21T18:44:00Z"^^xsd:dateTime ; meta:valEffectiveDate "2021-09-21T18:44:00Z"^^xsd:dateTime . # IN-ACTIV-041.xml # EXAMPLE - The physical implementation of Line RZ17801 # ended its participation in the Activiy A457438 (declared as HYDROSTATIC TESTING) # in the Role of HYDROSTATICALLY TESTED OBJECT # on 2021-11-14T18:44:00Z ex:be6e2aaa-0b03-4246-9d75-6e06a311cda4 rdf:type tpl:ParticipationOfPhysicalObjectInActivity ; tpl:hasActivity ex:b19c7864-7cff-494b-8bcb-c49246302dfb ; # A457438 tpl:hasParticipant ex:43974c9d-610d-4fc6-8ac9-26216cbc0652 ; # physical implementation of Line RZ17801 tpl:hasParticipantRole rdl:RDS2221129 ; # HYDROSTATICALLY TESTED OBJECT tpl:valEndDate "2021-11-14T18:44:00Z"^^xsd:dateTime ; meta:valEffectiveDate "2021-11-14T18:44:00Z"^^xsd:dateTime . # IN-ACTIV-042.xml # EXAMPLE - An unidentified member of the Class 'MARINE ATMOSPHERE' # began participation in an individual CORROSION Activity A34723212 # in the Role of CORRODING AGENT # on 2021-09-21T18:44:00Z ex:d3e4cb60-f8c3-4f7a-90ca-8e33ae940f54 rdf:type tpl:BegunParticipationOfClassInActivity ; tpl:hasActivity ex:6ba2d237-b173-4445-913b-a590400d7305 ; # A34723212 tpl:hasParticipantType rdl:RDS14316220 ; # MARINE ATMOSPHERE tpl:hasParticipantRole rdl:RDS2227753 ; # CORRODING AGENT tpl:valStartDate "2021-09-21T18:44:00Z"^^xsd:dateTime ; meta:valEffectiveDate "2021-09-21T18:44:00Z"^^xsd:dateTime . # IN-ACTIV-043.xml # EXAMPLE - An unidentified member of the Compressor Class 'MODEL Hm-347x' # has been purchased through PURCHASING Activity A5743832 # on 2021-09-21T18:44:00Z ex:d3e4cb60-f8c3-4f7a-90ca-8e33ae940f54 rdf:type tpl:EndedParticipationOfClassInActivity ; tpl:hasActivity ex:94341ba9-3c3f-4fc3-9a24-dcf87ecbcd5b ; # A5743832 tpl:hasParticipantType xyz:Hm-347x ; # MODEL Hm-347x of XYZ Ltd tpl:hasParticipantRole rdl:RDS222362 ; # SUBJECT tpl:valEndDate "2021-09-21T18:44:00Z"^^xsd:dateTime ; meta:valEffectiveDate "2021-09-21T18:44:00Z"^^xsd:dateTime . # IN-ACTIV-044.xml # EXAMPLE - An unidentified member of the 'BEAM' Class # does NOT participate in # the SUPPORTING Activiy of Line RZ81247 ex:6ce9718d-9f31-4e8d-bf6e-7091a66956e3 rdf:type tpl:ParticipationOfClassInActivityYesNo ; tpl:hasActivity ex:91600327-6642-4e2c-981b-cafca961a116 ; # A2427375 tpl:hasParticipantType rdl:RDS5754776 ; # BEAM tpl:hasParticipantRole rdl:RDS2223575 ; # SUPPORTING OBJECT tpl:valApplicableYesNo "false"^^xsd:boolean ; meta:valEffectiveDate "2021-09-21T18:44:00Z"^^xsd:dateTime . # IN-ACTIV-050.xml # EXAMPLE - John Doe began participation in ACCOUNTING # in the Role of MANAGER(role) # on 2021-09-21T18:44:00Z ex:3bd1ca96-42fa-45ac-bc76-7a87b725711e rdf:type tpl:BegunParticipationOfPhysicalObjectInActivityType ; tpl:hasActivityType rdl:RDS9697562 ; # ACCOUNTING tpl:hasParticipant ex:f67a776a-0c5e-4bae-9b04-f7c1895970e0 ; # John Doe tpl:hasParticipantRole rdl:RDS222426 ; # MANAGER(role) tpl:valStartDate "2021-09-21T18:54:00Z"^^xsd:dateTime ; meta:valEffectiveDate "2021-09-21T18:54:00Z"^^xsd:dateTime . # IN-ACTIV-051.xml # EXAMPLE - John Doe ended participation in ACCOUNTING # in the Role of MANAGER(role) # on 2021-09-21T18:54:00Z ex:3bd1ca96-42fa-45ac-bc76-7a87b725711e rdf:type tpl:BegunParticipationOfPhysicalObjectInActivityType ; tpl:hasActivityType rdl:RDS9697562 ; # ACCOUNTING tpl:hasParticipant ex:f67a776a-0c5e-4bae-9b04-f7c1895970e0 ; # John Doe tpl:hasParticipantRole rdl:RDS222426 ; # MANAGER(role) tpl:valEndDate "2021-09-21T18:54:00Z"^^xsd:dateTime ; meta:valEffectiveDate "2021-09-21T18:54:00Z"^^xsd:dateTime . # IN-ACTIV-052.xml # EXAMPLE - John Doe does not participate # inACCOUNTING # in the Role of MANAGER(role) ex:3bd1ca96-42fa-45ac-bc76-7a87b725711e rdf:type tpl:ParticipationOfPhysicalObjectInActivityTypeYesNo ; tpl:hasActivityType rdl:RDS9697562 ; # ACCOUNTING tpl:hasParticipant ex:f67a776a-0c5e-4bae-9b04-f7c1895970e0 ; # John Doe tpl:hasParticipantRole rdl:RDS222426 ; # MANAGER(role) tpl:valApplicableYesNo "false"^^xsd:boolean ; meta:valEffectiveDate "2021-09-21T18:54:00Z"^^xsd:dateTime . # IN-ACTIV-060.xml # EXAMPLE - A pump for tag P-101 # in the Role of MANUFACTURED OBJECT # has been manufactured by XYZ Ltd # in the Role of MANUFACTURER(role) # in Activity A374221 (classified as MANUFACTURING) ex:3a2e2228-7238-4e7e-bf80-5e3b79e79d31 rdf:type tpl:EndingOfParticipationOfTwoPhysicalObjectsInSameActivity ; tpl:hasActivity ex:58540b60-6064-4d56-bb65-be1800a9a3b5 ; # A374221 tpl:hasParticipant1 ex:7e16af6f-10b5-44f5-823a-c94954bfe135 ; # pump for tag P-101 tpl:hasParticipantRole1 rdl:RDS2226060 ; # MANUFACTURED OBJECT tpl:hasParticipant2 ex:e4d2bc19-a5a8-4f2c-b935-0d77547a2a2a ; # XYZ Ltd tpl:hasParticipantRole2 rdl:RDS2223263 ; # MANUFACTURER(role) meta:valEffectiveDate "2021-12-14T14:07:00Z"^^xsd:dateTime . # IN-ACTIV-080.xml # EXAMPLE - The Activity A543859 (WELDING of line RZ17801) # is involved-by-reference in an Activity A563846 (PROGRESS REPORTING on Area 17 in 2021 week 16) # in the Role of REPORTED OBJECT. ex:98669b5b-daaf-4876-aa75-61fca128d900 rdf:type tpl:InvolvementByReferenceOfIndividualInActivity ; tpl:hasActivity ex:a204b3c6-bba3-46ce-a323-3c95ba801382 ; # A563846 (reporting) tpl:hasInvolved ex:7945174f-3893-45f0-8e92-4caf95966b96 ; # A543859 (welding) tpl:hasInvolvementRole rdl:RDS2220203 ; # REPORTED OBJECT meta:valEffectiveDate "2021-09-21T14:47:00Z"^^xsd:dateTime . # IN-ACTIV-100.xml # EXAMPLE - Any member of [DOCUMENT] class [Welding Instruction 12345] # is involved by reference in the Activity [Welding of Line RZ17801] # in the Role of [INSTRUCTION(role)]. ex:b1b8fa57-6f07-4328-9dc7-6002797dae12 rdf:type tpl:InvolvementByReferenceOfClassInActivity ; tpl:hasActivity ex:6c962304-114a-4c9d-b663-8073a096cd19 ; # A4823832 tpl:hasInvolved ex:7e091695-1f65-46f6-bed4-04ff5053de69 ; # Welding Instruction 12345 tpl:hasInvolvementRole rdl:RDS2220036 ; # INSTRUCTION(role) meta:valEffectiveDate "2021-10-15T11:44:00Z"^^xsd:dateTime . # IN-ACTIV-101.xml # EXAMPLE - Any member of [DOCUMENT] class [Welding Instruction 12345] # is not involved by reference in the Activity [Welding of Line RZ17801] # in the Role of [INSTRUCTION(role)]. ex:bece8fcd-b0c8-4ada-90b2-80d06e239e15 rdf:type tpl:InvolvementByReferenceOfClassInActivity ; tpl:hasActivity ex:6c962304-114a-4c9d-b663-8073a096cd19 ; # A3484274 tpl:hasInvolved ex:7e091695-1f65-46f6-bed4-04ff5053de69 ; # Welding Instruction 12345 tpl:hasInvolvementRole rdl:RDS2220036 ; # INSTRUCTION(role) tpl:hasApplicableYesNo "false"^^xsd:boolean ; meta:valEffectiveDate "2021-10-15T12:14:00Z"^^xsd:dateTime . # IN-ACTIV-160.xml # EXAMPLE - OBSERVING Activity A584332 # results in the information "Corrosion electrode KE-104 has a corrosion rate of 1.5 mm/year" # as expressed by an instance of template # IndividualHasPropertyWithValue. ex:d0af356e-090b-4c13-aea0-35eebbc0a84c rdf:type tpl:RecognitionOfInformation ; tpl:hasActivity ex:ee54ec45-571c-4df2-a175-e1349f39ddce ; # A584332 tpl:hasRecognized ex:611c45cc-b020-44d3-8f22-00b4801b385c ; # Template instance with label "[CORROSION PROBE] individual [KE-104] has a [CORROSION RATE] of [1.5] [MILLIMETRE PER YEAR]" tpl:hasRecognitionType rdl:RDS2220203 ; # RECOGNITION BY OBSERVATION meta:valEffectiveDate "2021-09-21T21:01:00Z"^^xsd:dateTime . # IN-ACTIV-240.xml # EXAMPLE - Manufacturing activity A342321 # has begun the existence # of Actual PUMP P-101 ex:77c5898d-3642-4493-9051-c5a2dfbbd5a5 rdf:type tpl:ActivityCausesBegunIndividual ; tpl:hasActivity ex:bdc4797a-1a84-4c67-be5a-d6e108c65ac7 ; # A342321 tpl:hasBegunIndividual ex:97bd1602-b5a6-415a-9938-8803f605bf98 ; # P-101 meta:valEffectiveDate "2021-12-14T16:51:00Z"^^xsd:dateTime . # IN-ACTIV-280.xml # EXAMPLE - The Activity A5833422(classified as DEMOLISHING), # ends the existence #of Actual PUMP P-101. ex:533d4596-90f9-4e42-8c8d-8f27c33a95e7 rdf:type tpl:ActivityCausesEndedIndividual ; tpl:hasActivity ex:eb0d6e91-a69f-406c-a7c1-e62ca34b7e69 ; # A5833422 tpl:hasEndedIndividual ex:cf8ac556-2331-4163-ba3d-79b02bdcda50 ; # myPump meta:valEffectiveDate "2021-12-15T14:04:00Z"^^xsd:dateTime . # IN-ACTIV-400.xml # EXAMPLE - This temperature measurement exposes # that John Doe # has a BODY TEMPERATURE of 37 DEGREE CELSIUS. ex:1a53964a-5c53-43f5-8a85-0e0938715e48 rdf:type tpl:MeasuringAPropertyOfAnIndividual ; tpl:hasActivity ex:544c2d4e-8f48-40a6-9ff6-d56df0438e8a ; # the declared Activity tpl:hasPropertyPossessor ex:365c41f1-4815-4d45-9a90-0cbc6f88829c ; # John Doe tpl:hasPropertyType rdl:RDS2226482 ; # BODY TEMPERATURE tpl:valPropertyValue "37"^^xsd:decimal ; tpl:hasScale rdl:RDS1322684 ; # DEGREE CELSIUS meta:valEffectiveDate "2023-03-01T13:36:00Z"^^xsd:dateTime . # IN-ACTIV-440.xml # EXAMPLE - The pressure of Stream S47 # is stored as a time series, # measured between the start and finish of a night shift: 2021-12-15T00:00:00Z and 2021-12-15T08:00:00Z. ex:4730c119-7b22-48f5-8205-038803b06147 rdf:type tpl:MeasuringPropertyTimeSeriesOfIndividual ; tpl:hasActivity ex:71220511-a92a-44ed-8d17-ce8852c67c2a ; # declared Activity tpl:hasPropertyPossessor ex:9ccad474-ce31-42b0-9459-5057f069db69 ; # PT-101 tpl:hasPropertyType rdl:RDS7345161 ; # GAUGE PRESSURE tpl:valTimeSeries ex:c7a871e2-43a8-4530-9141-da5048b9e176 ; # see below tpl:hasScale rdl:RDS1348874 ; # BAR GAUGE tpl:valStartTime "2021-12-15T00:00:00Z"^^xsd:dateTime ; tpl:valEndTime "2021-12-15T00:08:00Z"^^xsd:dateTime ; meta:valEffectiveDate "2021-12-15T08:01:00Z"^^xsd:dateTime . ## ex:c7a871e2-43a8-4530-9141-da5048b9e176 ex:hasTimeSeries ## date Pts mean min max variance stdErr ## 1 2021-12-15 00:01:00.0 1 15.06154 14.96886 15.15625 0.002655015 0.006652087 ## 2 2021-12-15 00:02:00.0 1 14.99858 14.93720 15.04274 0.001254117 0.004571866 ## 3 2021-12-15 00:03:00.0 1 15.26231 15.03502 15.56683 0.041437537 0.026279757 ## 4 2021-12-15 00:04:00.0 1 15.45351 15.38553 15.53449 0.001174759 0.004424851 ## 5 2021-12-15 00:05:00.0 1 15.35306 15.23799 15.42346 0.003526443 0.007666423 ## 6 2021-12-15 00:06:00.0 1 15.12807 15.05846 15.23494 0.003764170 0.007920616 ## 7 2021-12-15 00:07:00.0 1 15.26231 15.03502 15.56683 0.041437537 0.026279757 ## 8 2021-12-15 00:08:00.0 1 15.35307 15.23801 15.42346 0.003526443 0.007666423" # IN-ACTIV-480.xml # EXAMPLE - John Doe has approved # the direct connection between the physical implementations of Line RZ17801 and Pump P-101 # with the status "Approved". ex:89b0cf09-2179-4041-9bee-aef605e6f227 rdf:type tpl:ApprovalWithStatusOfRelationshipInTemplate ; tpl:hasApprover ex:c7f173bb-e15c-4f86-8eac-66715067fd54 ; # John Doe tpl:hasStatus rdl:RDS222617 ; # APPROVED tpl:hasRepresentingTemplate "ex:67c2704f-6af6-49b6-9147-e9b39042b53b"^^xsd:anyUri ; meta:valEffectiveDate "2021-12-16T14:07:00Z"^^xsd:dateTime . # IN-ACTIV-520.xml # EXAMPLE - myPump, with Asset Number AN654321, # is installed, # where that installed item is a counterpart of NonActual tag P-101 as designed. ex:a28c6aa9-9368-489f-86c9-575551106fc2 rdf:type tpl:InstallingPhysicalObjectInFunctionalLocation ; tpl:hasInstallationActivity ex:f00c2631-88f4-4960-b18a-51dbfa2f0b77 ; # A4734822 tpl:hasDesignedObject ex:ed339c26-9a8b-48c2-a2f2-ed85f35c2843 ; # P-101 tpl:hasActualObject ex:255bd3cd-574d-442c-afe9-3e600866c905 ; # AN654321 tpl:hasInstalledObject ex:3f65ab8c-66f7-4dde-8983-0028e1c528d3 ; # P-101/AN654321 meta:valEffectiveDate "2021-12-17T14:07:00Z"^^xsd:dateTime . # IN-ACTIV-560.xml # EXAMPLE - myPump, with Asset Number AN654321 # has been uninstalled # from functional location P-101. ex:5ed3edbe-7b5d-4083-ab62-d76886853fa5 rdf:type tpl:UninstallingPhysicalObjectInFunctionalLocation ; tpl:hasUninstallationActivity ex:d64cebd8-234a-4baf-883a-333e62d91ee1 ; # A5925922 tpl:hasDesignedObject ex:ed339c26-9a8b-48c2-a2f2-ed85f35c2843 ; # P-101 tpl:hasActualObject ex:255bd3cd-574d-442c-afe9-3e600866c905 ; # AN654321 tpl:hasInstalledObject ex:3f65ab8c-66f7-4dde-8983-0028e1c528d3 ; # P-101/AN654321 meta:valEffectiveDate "2021-12-17T13:27:00Z"^^xsd:dateTime .

    #Templates about one PossibleIndividual, related to: CLASSIFICATION

    # IN-CLSIF-100.xml # EXAMPLE - Pump 21-P-101 is classified as CENTRIFUGAL PUMP. ex:4cef7d77-aa8e-49b8-a962-e607494fd38f rdf:type tpl:ClassificationOfIndividual ; tpl:hasClassified ex:24779178-99b3-43c2-95a1-ed2662a5abdc ; # 21-P-101 tpl:hasClassifier rdl:RDS416834 ; # CENTRIFUGAL PUMP meta:valEffectiveDate "2021-07-18T13:59:00Z"^^xsd:dateTime . # IN-CLSIF-200.xml # EXAMPLE - Pump with asset number AN5433839 # does not comply # with the product model of which it was a member when it was manufactured and inspected. ex:3f29ee9f-5341-4034-b1da-165aa4914136 rdf:type tpl:NoncomplianceWithClassOfIndividual ; tpl:hasNonComplier ex: ; # Pump with asset number AN5433839 tpl:hasTargetClass xyz:H375 ; # Model H375 of XYZ Corp. meta:valEffectiveDate "2021-12-17T16:07:00Z"^^xsd:dateTime .

    #Templates about one PossibleIndividual, related to: DESCRIPTION

    # IN-DESCR-100.xml # EXAMPLE - MyPump # has as Service Description "Boiler Feedwater to E-121" # in the Korean language and Hangul format ex:4478ca0a-0d97-4417-9c86-a943290d41f6 rdf:type tpl:ClassifiedDescriptionOfIndividual ; tpl:hasDescribed ex:801d3c9e-d10b-42d2-ba7c-15a9536606a0 ; # P-101 tpl:hasDescriptor "E-121에 대한 보일러 급수"; # 'Boiler Feed water to E-121' in the Korean language and Hangul format tpl:hasDescriptorType xyz:R32732 ; # XYZ Corp. Equipment Description In Korean Language and in HANGUL format. meta:valEffectiveDate "2021-09-23T12:07:00Z"^^xsd:dateTime . # IN-DESCR-300.xml # EXAMPLE - My B+R model EXE/TE2212/S IP66 Explosion Protected Enclosure # has a nameplate with a description of that device (description itself not given). ex:8b0b7ac6-6486-49b1-a133-66ec5d88aaee rdf:type tpl:DescriptionOfIndividualWithClassifiedSign ; tpl:hasDescribed ex:f5bb2359-c8b5-4b4a-b458-4e43bec7f77a ; # EXE/TE2212/S tpl:hasSign ex:1cf15f8c-c8fd-476d-8bf2-893e3f06e8dd ; # nameplate for EXE/TE2212/S tpl:hasSignType br:R3734 ; # defined in B+R local RDL extension meta:valEffectiveDate "2021-12-17T14:07:00Z"^^xsd:dateTime .

    #Templates about one PossibleIndividual, related to: DOCUMENT

    # IN-DOCS-080.xml # EXAMPLE - The "anchor" of Isometric KH-3498 # has been initiated # at the given date-time. ex:efccca44e3ea4352869ac06e42a4e10c rdf:type tpl:DocumentInitiation ; tpl:hasInitiatedDocument ex:f81baf5e-e7e5-49c0-bcc7-4f41496c5b22 ; # KH-3498 master tpl:hasActivity ex:d366efac-53c7-470d-b4d6-b84fad1a7cd8 ; # A348593 ; tpl:valInitiationDate "2022-02-01T15:27:00Z"^^xsd:dateTime ; meta:valEffectiveDate "2022-02-01T15:27:00Z"^^xsd:dateTime . # IN-DOCS-160.xml # EXAMPLE - Isometric KH-3498 rev0 # has been created # at the given date-time. ex:efccca44e3ea4352869ac06e42a4e10c rdf:type tpl:DocumentCreation ; tpl:hasInitiatedDocument ex:f7776844-6528-499e-a91f-03f0e581c7a2 ; # KH-3498-rev0 tpl:hasMember ex:4963bbbc-3f3a-43cd-8932-d32a4e527451 ; # physical record tpl:hasActivity ex:68f49988-b3f6-4a25-a202-3f1f7d1f3545 ; # A348594 ; tpl:valCreationDate "2022-02-01T15:27:00Z"^^xsd:dateTime ; meta:valEffectiveDate "2022-02-01T15:27:00Z"^^xsd:dateTime . # IN-DOCS-200.xml # EXAMPLE - Isometric KH-3498-rev0 has been reviewed with a Status REVIEWED BY CLIENT # at a given date-time. ex:efccca44e3ea4352869ac06e42a4e10c rdf:type tpl:DocumentReview ; tpl:hasReviewedDocument ex:f7776844-6528-499e-a91f-03f0e581c7a2 ; # KH-3498-rev0 tpl:hasMember ex:9e93e7de-6e52-456b-bcbf-6bc2bcb9131f ; # tpl:hasStatus rdl:RDS2229345 ; # REVIEWED BY CLIENT tpl:hasActivity ex:68f49988-b3f6-4a25-a202-3f1f7d1f3545 ; # A348596 ; tpl:valReviewDate "2022-02-02T16:13:00Z"^^xsd:dateTime ; meta:valEffectiveDate "2022-02-02T16:13:00Z"^^xsd:dateTime . # IN-DOCS-240.xml # EXAMPLE - Isometric KH-3498-rev0 # has been approved with Status AFC # at the given date-time. ex:efccca44e3ea4352869ac06e42a4e10c rdf:type tpl:DocumentApproval ; tpl:hasApprovedDocument ex:f7776844-6528-499e-a91f-03f0e581c7a2 ; # KH-3498-rev0 tpl:hasMember ex:9e93e7de-6e52-456b-bcbf-6bc2bcb9131f ; # physical record tpl:hasStatus rdl:RDS2229162 ; # APPROVED FOR CONSTRUCTION (AFC) tpl:hasActivity ex:dbb1077c-ab91-43b8-8e5a-25a92e63bbf5 ; # A348597 ; # Approval activity tpl:valApprovalDate "2022-02-03T12:14:00Z"^^xsd:dateTime ; meta:valEffectiveDate "2022-02-03T12:14:00Z"^^xsd:dateTime . # IN-DOCS-320.xml # EXAMPLE - Isometric KH-3498 rev0 # has been published in ApprovedForConstruction Status, # a result of a publishing Activity # at the given date-time. ex:9afe4110-3072-495a-91d5-f35269c81bf8 rdf:type tpl:DocumentPublication ; tpl:hasPublishedDocument ex:f7776844-6528-499e-a91f-03f0e581c7a2 ; # KH-3498-rev0 tpl:hasMember ex:9e93e7de-6e52-456b-bcbf-6bc2bcb9131f ; # physical record tpl:hasStatus rdl:RDS2229162 ; # APPROVED FOR CONSTRUCTION (AFC) tpl:hasActivity ex:dbb1077c-ab91-43b8-8e5a-25a92e63bbf5 ; # A348598 ; # Publication activity tpl:valPublicationDate "2022-02-05T11:18:00Z"^^xsd:dateTime ; meta:valEffectiveDate "2022-02-05T11:18:00Z"^^xsd:dateTime . # IN-DOCS-321.xml # EXAMPLE - Isometric KH-3498 rev0 # is planned to be published in AFC Status # on May 25th 2023. ex:5df393b1-5f9a-49e1-a2bb-e36cbeed7f3a rdf:type tpl:PlannedDocumentPublication ; tpl:hasToBePublishedDocument ex:f7776844-6528-499e-a91f-03f0e581c7a2 ; # KH-3498-rev0 tpl:hasStatus rdl:RDS2229162 ; # APPROVED FOR CONSTRUCTION (AFC) tpl:hasPlannedActivity ex:897960bf-343b-4770-b707-8bb8e267ec7d ; # See scope note tpl:valPlannedPublicationDate "2023-05-25T00:00:00Z"^^xsd:dateTime ; meta:valEffectiveDate "2022-02-05T11:18:00Z"^^xsd:dateTime . # IN-DOCS-330.xml # EXAMPLE - Isometric KH-3498-rev0 # has been received # at the given date-time ex:89c669a8-0c03-4fd9-8c38-0093f61745be rdf:type tpl:DocumentReceipt ; tpl:hasReceivedDocument ex:f7776844-6528-499e-a91f-03f0e581c7a2 ; # KH-3498-rev0 tpl:hasMember ex:9e93e7de-6e52-456b-bcbf-6bc2bcb9131f ; # the record tpl:hasActivity ex:7ff2c9ea-ee7d-42a6-a5f6-f7f7a990a825 ; # see scope note tpl:valReceivalDate "2022-02-07T14:54:00Z"^^xsd:dateTime ; meta:valEffectiveDate "2022-02-07T14:54:00Z"^^xsd:dateTime . # IN-DOCS-400.xml # EXAMPLE - John Doe, # PROJECT MANAGER, # published pump data sheet SP-3401-rev2 # in the Status "For Approval" # on Nov. 24th 2021 ex:7b37090c-d5bd-466f-9442-1701f76d8b98 rdf:type tpl:DocumentPublishingWithResponsibleParty ; tpl:hasPublishedDocument ex:17b4839e-98e1-409f-9199-d92154119cbc ; # SP-3401-rev2 tpl:hasMember ex:3ce37e10-8595-4b4e-8148-715a059a35d8 ; # see scope note tpl:hasActivity ex:e605537c-a586-4bdb-89e1-679c4e8930ba ; # A453648 , see scope note tpl:hasPublicationStatus rdl:RDS2224443 ; # ISSUED FOR APPROVAL (IFA) tpl:valPublishingDate "2021-11-24T00:00:00Z"^^xsd:dateTime ; tpl:hasResponsibleParty ex:edde623c-abdc-418d-bb64-d1a1f05bcffd ; # John Doe tpl:hasPartyType rdl:RDS2229346 ; # PROJECT MANAGER meta:valEffectiveDate "2021-11-24T00:00:00Z"^^xsd:dateTime . # IN-DOCS-480.xml # EXAMPLE - Isometric KH-3498 rev0 # has been created # at the given date-time. ex:e2c05329-96c2-4155-bb2c-c070ab90ef9b rdf:type tpl:DocumentCreation ; tpl:hasInitiatedDocument ex:58ff5697-fcf8-4146-995b-5002936da034 ; # KH-3498-rev1 tpl:hasMember ex:dba2f97f-e7b1-44e5-948a-2f82aac81708 ; # physical record tpl:hasActivity ex:ef783d46-776a-4ce4-ad24-e878ac41c635 ; # A348599 ; tpl:valCreationDate "2022-02-08T13:37:00Z"^^xsd:dateTime ; meta:valEffectiveDate "2022-02-08T13:37:00Z"^^xsd:dateTime . # IN-DOCS-640.xml # EXAMPLE - The tag number P-101 # is mentioned #on P&D Hk-5732-rev1 ex:34f85b90-5487-48f1-9ecc-58c7d5bcdee8 rdf:type tpl:ReferenceToIndividualOnDocument ; tpl:hasReferred ex:51e558d2-d9b3-43c6-87be-491cdfd0fc99 ; # P-101 tpl:hasDocument ex:e1aebf12-3fe4-40b6-a280-16200612992c ; # Hk-5732-rev1 meta:valEffectiveDate "yyyy-mm-ddThh:mm:ss.sZ"^^xsd:dateTime . # IN-DOCS-680.xml # EXAMPLE - The Online Processing Facility # is represented # with a Duty Specification, # of which the information content, language, and format shall comply with the representation type. ex:58dfed9c-909e-4251-b724-6890fd4da129 rdf:type tpl:RepresentationOfIndividual ; tpl:hasRepresented ex:cb0ee133-bfd7-4d0e-9633-40c8a23bc933 ; # Online Processing Facility tpl:hasRepresentation ex:816719ac-8665-42e2-ac9d-af90ec3e2c10 ; # contents of Duty Specification tpl:hasRepresentationType xyz:R83732 ; # ClassOfClassOfInformationRepresentation in local RDL extension meta:valEffectiveDate "2023-02-09T10:01:00Z"^^xsd:dateTime . # IN-DOCS-720.xml # EXAMPLE - Pump P-101 # is represented # on Pump Specification NY-4863 rev.2, # that is an API 610 Pump Specification in US English and ASCII ex:ed26d9f8-443f-4630-81e9-ce423d79d7fc rdf:type tpl:ClassifiedRepresentationOfIndividualOnDocument ; tpl:hasRepresented ex:51e558d2-d9b3-43c6-87be-491cdfd0fc99 ; # P-101 tpl:hasRepresentation ex:fe340e5f-d864-40a0-bc5d-985ac4dad3ed ; # ID of contents of Pump Specification tpl:hasRepresentationType xyz:R54738 ; # API 610 Pump Specification in US English and ASCII in local RDL extension tpl:hasDocument ex:2cac667f-3f3e-4d91-a941-2a6026b55b37 ; # NY-4863 rev.2 meta:valEffectiveDate "2022-02-09T11:01:00Z"^^xsd:dateTime . # IN-DOCS-800.xml # EXAMPLE - Information about pump P-101 # is represented # on Pump Specification NY-4863 rev.2 # by a set of templates that represent the data elements of that specification. ex:93dedaaa-4277-4209-b2ff-7ce9acce590a rdf:type tpl:RepresentationOfIndividualOnDocumentWithTemplateSet ; tpl:hasRepresented ex:51e558d2-d9b3-43c6-87be-491cdfd0fc99 ; # P-101 tpl:hasDocument ex:2cac667f-3f3e-4d91-a941-2a6026b55b37 ; # NY-4863 rev.2 tpl:hasTemplateSet ex:b009b368-93a4-4991-8f33-7302285d85c1 ; # Templates of NY-4863 rev.2 tpl:hasRepresentation ex:fe340e5f-d864-40a0-bc5d-985ac4dad3ed ; # ID that represents contents of NY-4863 rev.2 meta:valEffectiveDate "2022-02-09T12:09:00Z"^^xsd:dateTime .

    #Templates about one PossibleIndividual, related to: EXISTENCE

    # IN-EXIST-100.xml # EXAMPLE - Pump P-102 with Serial Number is delivered at site and is registered as Asset # as a temporal part of P-102 ex:9b2cb8a4-e797-4c1d-9837-0734ceaeef05 rdf:type tpl:IndividualHasTemporalPart ; tpl:hasTemporalWhole ex:e836d6a9-12d6-4481-9e33-17089c9ebe08 ; # P-102 tpl:hasTemporalPart ex:be3287f1-ceac-41ff-944a-90fa8e3afcbe ; # P-102_20220210 meta:valEffectiveDate "2022-02-10T15:58:00Z"^^xsd:dateTime . # IN-EXIST-200.xml # EXAMPLE - The event EV_293011 # begins the transportation activity A698448 of my pump. ex:a9245cee-53d6-48cb-b3fc-688832c847c1 rdf:type tpl:BeginningOfIndividualAtEvent; tpl:hasBegunIndividual ex:949b7245-55a5-4867-a5a5-bd61ce2c5049 ; # the declared transporation activity A698448 tpl:hasEvent ex:479d5550-5434-4896-b82e-f067c03a0e6d ; # the declared event EV_293011 meta:valEffectiveDate "2021-09-20T21:14:00Z"^^xsd:dateTime. # IN-EXIST-400.xml # EXAMPLE - MyCar # ended its existence # at a Traffic Accident on April 24, 2012. ex:3773d102-d247-4781-8295-36c5b778f8e3 rdf:type tpl:EndingOfIndividualAtEvent; tpl:hasEndedIndividual ex:4a7082aa-c72a-4b49-a5bc-6fe04640657d ; # the declared car myCar tpl:hasEvent ex:dff80045-df93-4638-a0b4-63ee31f5479b ; # the declared event EV_294776 meta:valEffectiveDate "2021-09-21T22:13:00Z"^^xsd:dateTime.

    #Templates about one PossibleIndividual, related to: FUNCTION

    # IN-FUNC-100.xml # EXAMPLE - John Doe # is a Welder, certified for AWS GTAW Pipe (Stainless Steel) ex:86b668e7-a9cb-4bb4-819b-c201fe203fa6 rdf:type tpl:SkillOfAPerson ; tpl:hasPerson ex:fb8d3507-a45c-4a3d-ad05-9b8b4d56eff3 ; # John Doe tpl:hasSkill exrdl:R387482 ; # "Welder, certified for AWS GTAW Pipe (Stainless Steel)" in local RDL extension meta:valEffectiveDate "yyyy-mm-ddThh:mm:ss.sZ"^^xsd:dateTime .

    #Templates about one PossibleIndividual, related to: IDENTIFICATION

    # IN-IDENT-100.xml # EXAMPLE - NonActualIndividual B14-V-132 # is identified with an Equipment Number # to XYZ Corp. rules. ex:763c75da-97c1-4b4e-b699-cf616c7c7a5d rdf:type tpl:ClassifiedIdentificationOfIndividual ; tpl:hasIdentified ex:f096ecc1-2f1f-47dc-b70f-724394aabd95 ; # B14-V-132 tpl:hasIdentifier "B14-V-132" ; tpl:hasIdentifierType xyz:R438482 ; # Equipment Number to XYZ Corp. rules meta:valEffectiveDate "2021-09-21T10:24:00Z"^^xsd:dateTime . # IN-IDENT-150.xml # EXAMPLE - The label of Vessel "B14-V-132" has been changed to "B14-V-133" ex:bdb0b529-ab9c-4fd2-86f2-945291eef5c3 rdf:type tpl:LabelChangeOfIndividual ; tpl:hasIdentified ex:49515d26-3794-47e4-b119-228c41f95153 ; # B14-V-132 (as declared) tpl:valOldIdentifier "B14-V-132"^^dm:ExpressString ; tpl:valNewIdentifier "B14-V-133"^^dm:ExpressString ; meta:valEffectiveDate "2022-02-13T12:46:00Z"^^xsd:dateTime . # IN-IDENT-200.xml # EXAMPLE - Installed Pump with Asset Number AN-6738292, at functional location P-101, is identified with a nameplate at its foundation. ex:55bbd230-10ce-4557-9fb6-e56032c4dea3 rdf:type tpl:IdentificationOfIndividualWithClassifiedSign ; tpl:hasIdentified ex:e92d1295-0461-4527-b331-ec71df62bb68 ; # AN-6738292 tpl:hasSign ex:2f366d0f-3980-41f0-b508-725e235664ee ; # declared physical nameplate with text "P-101" tpl:hasSignType rdl:RDS2229092 ; # NAMEPLATE meta:valEffectiveDate "2022-02-13T13:56:00Z"^^xsd:dateTime .

    #Templates about one PossibleIndividual, related to: INDIRECT PROPERTY

    # IN-INDPTY-100.xml # EXAMPLE - Pressure Transmitter PT-101 # has a CALIBRATED PRESSURE RANGE # with a Lower Bound of 0 # and an Upper Bound of 10 # on the BAR GAUGE scale ex:cccbe45b-d5cb-404a-a94b-fcccd7786ff8 rdf:type tpl:IndividualHasIndirectPropertyRange ; tpl:hasPossessor ex:3eedd954-ee24-41f4-8da3-20e6e6356fde ; # PT-101 tpl:hasIndirectPropertyType rdl:RDS1413237391 ; # CALIBRATED PRESSURE RANGE tpl:valLowerBound "0"^^xsd:decimal ; tpl:valUpperBound "10"^^xsd:decimal ; tpl:hasScale rdl:RDS1348874 ; # BAR GAUGE meta:valEffectiveDate "2021-01-15T13:45:00Z"^^xsd:dateTime . # IN-INDPTY-200.xml # EXAMPLE - ActualIndividual Vessel, that implements V-112, # has an MAWP # of 105 barg. ex:6180f197-1ba1-480c-a9e9-81259e0bb2cb rdf:type tpl:IndividualHasIndirectPropertyWithValue ; tpl:hasPossessor ex:a10d84f1-4f8f-4f73-b1e1-8c4b78e7d0b8 ; # Vessel, that implements V-112 tpl:hasIndirectPropertyType rdl:RDS13113437 ; # UPPER LIMIT ALLOWABLE WORKING PRESSURE tpl:valPropertyValue "105"^^xsd:decimal ; tpl:hasScale rdl:RDS1348874 ; # BAR GAUGE meta:valEffectiveDate "2021-09-21T12:48:00Z"^^xsd:dateTime . # IN-INDPTY-300.xml # EXAMPLE - The maximum value of the operating pressure # of Actual Stream S43743 # is 25.92 bar gauge # from a time series of flow rates during the shift between 2021-11-15T22:00:00Z and 2021-11-16T06:00:00Z . ex:a6ee45ad-8af0-4c4f-a09f-a081c0de3b1e rdf:type tpl:IIndividualHasIndirectPropertyWithMaximumValueInPeriodInTime ; tpl:hasPossessor ex:1a3b4ccf-e75f-42be-97a4-ee67c913df8d ; # Actual Stream S43743 tpl:hasIndirectPropertyType rdl:RDS1469240071 ; # OPERATING PRESSURE tpl:valMaximumValue "25.92"^^xsd:decimal ; tpl:hasScale rdl:RDS1348874 ; # BAR GAUGE tpl:valStartTime "2021-11-15T22:00:00Z"^^xsd:dateTime ; tpl:valEndTime "2021-11-16T06:00:00Z"^^xsd:dateTime ; meta:valEffectiveDate "2021-11-16T06:01:00Z"^^xsd:dateTime . # IN-INDPTY-500.xml # EXAMPLE - The Average Volume Flow Rate # of Actual Stream S43743 # is 32.4 m3/hr, # as calculated from a time series of flow rates during the shift between 2021-11-15T22:00:00Z and 2021-11-16T06:00:00Z . ex:8aee97a7-f87a-47b8-a10d-729e04687ef4 rdf:type tpl:IIndividualHasIndirectPropertyWithAverageValueInPeriodInTime ; tpl:hasPossessor ex:1a3b4ccf-e75f-42be-97a4-ee67c913df8d ; # S43743 tpl:hasIndirectPropertyType rdl:RDS16628457 ; # AVERAGE VOLUME FLOW RATE tpl:valAverageValue "32.4"^^xsd:decimal ; tpl:hasScale rdl:RDS1321064 ; # METRE CUBED PER HOUR tpl:valStartTime "2021-11-15T22:00:00Z"^^xsd:dateTime ; tpl:valEndTime "2021-11-16T06:00:00Z"^^xsd:dateTime ; meta:valEffectiveDate "2021-11-16T06:01:00Z"^^xsd:dateTime . # IN-INDPTY-700.xml # EXAMPLE - The minimum value of the operating pressure # of Actual Stream S43743 # is 19.76 bar gauge # as calculated from a time series of flow rates during the shift between 2021-11-15T22:00:00Z and 2021-11-16T06:00:00Z . ex:a6ee45ad-8af0-4c4f-a09f-a081c0de3b1e rdf:type tpl:IndividualHasIndirectPropertyWithMaximumValueInPeriodInTime ; tpl:hasPossessor ex:1a3b4ccf-e75f-42be-97a4-ee67c913df8d ; # S43743 tpl:hasIndirectPropertyType rdl:RDS1469240071 ; # OPERATING PRESSURE tpl:valMinimumValue "19.76"^^xsd:decimal ; tpl:hasScale rdl:RDS1348874 ; # BAR GAUGE tpl:valStartTime "2021-11-15T22:00:00Z"^^xsd:dateTime ; tpl:valEndTime "2021-11-16T06:00:00Z"^^xsd:dateTime ; meta:valEffectiveDate "2021-11-16T06:01:00Z"^^xsd:dateTime .

    #Templates about one or more PossibleIndividuals, related to: LOCATION

    # IN-LOCTN-100.xml # EXAMPLE - Individual Stream Segment S4382 # is contained # in pump P-101. ex:fb055488-ea04-4df0-a482-25f3bcc4b5a3 rdf:type tpl:ContainmentOfAnIndividual ; tpl:hashasContainer ex:797d7c94-404d-4874-a66d-db165f04495f ; # P-101 tpl:hashasContained ex:c151be2b-2557-4eef-abfd-5d2aa00f3323 ; # S4382 meta:valEffectiveDate "2021-09-21T11:27:00Z"^^xsd:dateTime . # IN-LOCTN-200.xml # EXAMPLE - Safety Relief Valve SV-243 # is located # above Vessel V-202. ex:a3aac5f2-0df4-4007-bea4-21f6807dff0d rdf:type tpl:RelativeLocationOfIndividual ; tpl:hasLocated ex:d4c66287-9616-471d-84c1-875a72e343c9 ; # V-202 tpl:hasLocator ex:8425ffaf-7026-40e6-9c6e-26ef412ee344 ; # SV-243 tpl:hasRelativeLocationType rdl:RDS2223275 ; # ABOVE meta:valEffectiveDate "2021-11-21T18:45:00Z"^^xsd:dateTime . # IN-LOCTN-250.xml # EXAMPLE - Safety Relief Valve SV-243 # is located # 3.50 metre above Vessel V-202. ex:bbd0cc38-5f3c-409e-b1e7-5e4e7666cdda rdf:type tpl:RelativeLocationOfIndividualWithDistance ; tpl:hasLocated ex:d4c66287-9616-471d-84c1-875a72e343c9 ; # V-202 tpl:hasLocator ex:8425ffaf-7026-40e6-9c6e-26ef412ee344 ; # SV-243 tpl:hasRelativeLocationType rdl:RDS2223275 ; # ABOVE tpl:hasPath ex:5a65f646-3be1-4c04-be34-40e7f8c44bde ; # auto-generated UUID, for later if details of path are required tpl:hasDistanceValue "3.50"^^xsd:decimal ; tpl:hasScale rdl:RDS1332674 ; # METRE meta:valEffectiveDate "2021-11-21T18:45:00Z"^^xsd:dateTime . # IN-LOCTN-300.xml # EXAMPLE - The centrepoint of pump P-101 # is located # at {233.65, 64.83} metre in 2D coordinate system of the Marshalling Yard. ex:43bb10ea-49e0-43d0-be5b-1b4dd7db32da rdf:type tpl:PositionOfIndividualIn2DCoordinateSystem ; tpl:hasPositioned ex:6320c40a-6651-48c0-a97f-0b22da3e779d ; # P-101 tpl:hasCoordinateSystem ex:f885064a-c58a-4e5f-bd4e-7974bf9a4a0e ; # Marshalling Yard 2D coordinate system tpl:valXCoordinate "233.65"^^xsd:decimal ; tpl:valYCoordinate "64.83"^^xsd:decimal ; meta:valEffectiveDate "2022-02-17T16:15:00Z"^^xsd:dateTime . # IN-LOCTN-400.xml # EXAMPLE - Valve, installed at functional location FCV-128, # is located # at {23.76,34.98,12.33 } metre in our site coordinate system ex:5742f5f3-eeca-4054-ac3a-a4d67b8bdd16 rdf:type tpl:PositionOfIndividualIn3DCoordinateSystem ; tpl:hasPositioned ex:e73b386f-9e2c-47a3-8ea4-16d5a805b90d ; # Valve, installed at functional location FCV-128 tpl:hasCoordinateSystem ex:29b16f70-c451-4970-8414-3e08da5a445a ; # Site coordinate system in metres, subClassOf rdl:RDS2220045 tpl:valXCoordinate "23.76"^^xsd:decimal ; tpl:valYCoordinate "34.98"^^xsd:decimal ; tpl:valZCoordinate "12.33"^^xsd:decimal ; meta:valEffectiveDate "2021-11-15T16:33:00Z"^^xsd:dateTime .

    #Templates about one PossibleIndividual, related to: MATERIAL

    # IN-MATL-100.xml # EXAMPLE - The body of myValve, FV-101-BODY, # is made of 316 STAINLESS STEEL. (=Classified as an object of 316SS) ex:bec26449-69f0-4f8b-9cf0-330ce5e34d9d rdf:type tpl:ClassificationOfIndividualWithClassOfMatter ; tpl:hasClassified ex:4a346b00-20bd-48ea-95ee-0e003e406762 ; # FV-101-BODY tpl:hasClassifier rdl:RDS2221635 ; # 316 STAINLESS STEEL meta:valEffectiveDate "2021-07-18T13:59:00Z"^^xsd:dateTime . # IN-MATL-500.xml # EXAMPLE - Stream S47 is in a liquid Phase. ex:f6ed613c-b3bc-452b-b16c-9982366851e6 rdf:type tpl:ClassificationOfIndividualWithPhase ; tpl:hasClassified ex:61c06b30-d51b-42c0-9ae6-2bbb4412ce0f ; # Stream S47 tpl:hasClassifier rdl:RDS222609 ; # LIQUID(phase) meta:valEffectiveDate "2021-07-18T13:59:00Z"^^xsd:dateTime .

    #Templates about one or more PossibleIndividuals, related to: OTHER RELATIONSHIP

    # IN-OTHRL-100.xml # EXAMPLE - Pump with Serial Number Wv438d2 # is a deliverable # of Project P1234 ex:1835e5f6-07ba-4b44-9753-f55c3b0afb0d rdf:type tpl:OtherRelationshipBetweenTwoIndividuals ; tpl:hasIndividualSubject ex:6320c40a-6651-48c0-a97f-0b22da3e779d ; # temporal part of SN-Wv438d2 installed at functional location P-101 tpl:hasIndividualObject ex:f158f2e0-01d8-448c-af34-0dbd05939c12 ; # Project P1234 tpl:hasRelationshipType rdl:RDS2228375 ; # IS DELIVERABLE OF meta:valEffectiveDate "2022-02-24T11:49:00Z"^^xsd:dateTime . # IN-OTHRL-200.xml # EXAMPLE - XYZ Corp. # manufactures # PUMP SYSTEMs of Model 123 (so members of that Class) ex:cebe0501-3be6-4944-a07c-74ef4487a90e rdf:type tpl:RelationshipBetweenIndividualAndClassOfIndividual ; tpl:hasIndividualSubject ex:7ea68eaa-bf77-4f64-91fe-a4f3b5204fec ; # XYZ Corp. tpl:hasClassObject ex:b7fbaba3-a37e-432e-a11c-ec6bd035db91 ; # Model 123 tpl:hasRelationshipType rdl:RDS2229354 ; # IS MANUFACTURER OF meta:valEffectiveDate "2022-02-23T12:22:00Z"^^xsd:dateTime .

    #Templates about one or more PossibleIndividuals, related to: PROPERTY and STATUS

    # IN-PTYST-100.xml # EXAMPLE - Vessel V-101 # has a mass # of 30.57 Metric Ton ex:fcbfda39-4d1a-4047-b4ca-45ab8d44fca4 rdf:type tpl:IndividualHasPropertyWithValue ; tpl:hasPropertyPossessor ex:847931fd-eade-4beb-b07d-a9e889611c19 ; # V-101 tpl:hasPropertyType rdl:RDS353339 ; # MASS tpl:valPropertyValue "30.37"^^xsd:decimal ; tpl:hasScale rdl:RDS2229868 ; # METRIC TON meta:valEffectiveDate "2021-07-27T10:19:00Z"^^xsd:dateTime . # IN-PTYST-125.xml # EXAMPLE - The labour cost for the maintenance of vessel V-101 is USD 1,875. ex:f6e0b814-746b-4351-9005-115b3448d0d9 rdf:type tpl:IndividualHasMonetaryValue ; tpl:hasPossessor ex:82f1fb2e-1d13-4225-9481-aae4fdc97a08 ; # Vessel, that implements V-101 tpl:hasCostType rdl:RDS2220202 ; # LABOUR COST tpl:valMonetaryValue "1,875.00"^^xsd:decimal ; tpl:hasCurrency rdl:RDS2228349 ; # USD meta:valEffectiveDate "2021-09-21T13:33:00Z"^^xsd:dateTime . # IN-PTYST-200.xml # EXAMPLE - The water stream S-34 # has a vapour pressure of 19.9 kPa # and a temperature of 60 degrees Celsius. ex:f584d8a5-ab3a-4b80-a42b-2f8dc35ef134 rdf:type tpl:IndividualHasTwoDimensionalPropertyWithValues ; tpl:hasPropertyType rdl:RDS2229352 ; # VAPOUR PRESSURE VS TEMPERATURE tpl:hasPossessor ex:70244682-2cd6-4f1f-8b8a-ff16484aef64 ; # S-34 tpl:hasPropertyType1 rdl:RDS358739 ; # VAPOUR PRESSURE tpl:valPropertyValue1 "19.9"^^xsd:decimal ; tpl:hasScale1 rdl:RDS2227188 ; # KILOPASCAL ABSOLUTE tpl:hasPropertyType2 rdl:RDS355859 ; # TEMPERATURE tpl:valPropertyValue2 "60"^^xsd:decimal ; tpl:hasScale2 rdl:RDS1322684 ; # DEGREE CELSIUS meta:valEffectiveDate "2021-11-15T13:45:00Z"^^xsd:dateTime . # IN-PTYST-300.xml # EXAMPLE - ActualIndividual that implements Pump P-101 # had an DUTY CYCLE # of 0.822 # calculated as active time / available time. ex:4ecee62d-f8c7-4676-a4da-64923cb0dd39 rdf:type tpl:IndividualHasRatioOf2MonotypeProperties ; tpl:hasPossessor ex:c7105ca4-3623-497e-ab81-0d1b3da7999a ; # implementation of P-101 tpl:hasMultidimensionalPropertyType rdl:RDS2227189 ; # DUTY CYCLE tpl:hasCommonPropertyType rdl:RDS407069 ; # DURATION tpl:valPropertyValue1 "60.33"^^xsd:decimal ; # active time tpl:valPropertyValue2 "73.42"^^xsd:decimal ; # available time tpl:hasCommonScale rdl:RDS1326734 ; # HOUR tpl:hasMappingType rdl:RDS11566410 ; # FUNCTION DIV tpl:valMappingResult "0.822"^^xsd:decimal ; meta:valEffectiveDate "2021-09-21T13:54:00Z"^^xsd:dateTime . # IN-PTYST-350.xml # EXAMPLE - Vessel V-101 # has a MASS # of 30.5 Metric Ton # that is an estimated value ex:f77ab75b-6ddb-49b2-8dfb-7070ea1ba590 rdf:type tpl:IndividualHasPropertyWithValue ; tpl:hasPossessor ex:847931fd-eade-4beb-b07d-a9e889611c19 ; # V-101 tpl:hasPropertyType rdl:RDS353339 ; # MASS tpl:valPropertyValue "30.5"^^xsd:decimal ; tpl:hasScale rdl:RDS2229868 ; # METRIC TON tpl:hasStatus rdl:RDS2220182 ; # ESTIMATED meta:valEffectiveDate "2021-09-21T13:33:00Z"^^xsd:dateTime . # IN-PTYST-400.xml # EXAMPLE - ActualIndividual, that implements P-101, # has the Status DEFECTIVE ex:b51c55bf-ed1d-4cf2-9de3-67c045ddf5fa rdf:type tpl:IndividualHasStatus ; tpl:hasPossessor ex:88b6efa5-eaad-4a9c-bae1-2c3aa51653c7 ; # ActualIndividual that implements P-101 tpl:hasStatus rdl:RDS222612 ; # DEFECTIVE meta:valEffectiveDate "2021-11-15T13:45:00Z"^^xsd:dateTime . # IN-PTYST-401.xml # EXAMPLE - ActualIndividual, that implements P-101, # has NOT the Status IN OPERATION ex:f178a270-47c2-4bf9-8156-78389e654dcb rdf:type tpl:IndividualHasNotGivenStatus ; tpl:hasPossessor ex:88b6efa5-eaad-4a9c-bae1-2c3aa51653c7 ; # ActualIndividual that implements P-101 tpl:hasNotStatus rdl:RDS2229927 ; # IN OPERATION meta:valEffectiveDate "2021-10-15T11:28:00Z"^^xsd:dateTime . # IN-PTYST-450.xml # EXAMPLE - Pump with serial number AW37423 # has a FACTORY WARRANTED Status # that ends # at a WARRANTY EXPIRATION EVENT # on 2026-11-24T24:00:00Z ex:81517702-5cbb-47d2-b6f7-a6411d5f813b rdf:type tpl:EndingOfStatusOfIndividualAtEvent ; tpl:hasPossessor ex:c579bf0c-d641-4abc-8313-bc2c4865de8e ; # AW37423 tpl:hasStatus rdl:RDS2229244 ; # FACTORY WARRANTED tpl:hasEvent ex:dd44323a-66e9-47f8-bbc3-7fe3160d8dab ; # Event classified as WARRANTY EXPIRATION EVENT tpl:hasEndDate "2026-11-24T24:00:00Z"^^xsd:dateTime ; meta:valEffectiveDate "2022-02-22T17:48:00Z"^^xsd:dateTime .

    #Templates about one or more PossibleIndividuals, related to: SHAPE

    # IN-SHAPE-100.xml # EXAMPLE - Tank T-101 # has a shape of a sphere # with a radius # with a length that is defined in a local RDL extension ex:fc8ed22a-c559-4a30-9f60-73364bb1000c rdf:type tpl:ShapeOfIndividualWithReferenceProperty ; tpl:hasPossessor ex:8f038387-bea0-46ca-a486-78e48f91cf51 ; # T-101 tpl:hasShapeType rdl:RDS2225772 ; # SPHERE(shape) tpl:hasDimensionType rdl:RDS358289 ; # RADIUS tpl:hasProperty exrdl:R458343 ; # standard length of 10 m defined in local RDL extension meta:valEffectiveDate "2021-11-17T13:55:00Z"^^xsd:dateTime . # IN-SHAPE-200.xml # EXAMPLE - PossibleIndividual T-101 # has a shape of a sphere # with a radius # of 10 m. ex:c46888de-fd2c-478e-9421-0024e7ea7441 rdf:type tpl:IndividualHasShapeWithDimension ; tpl:hasPossessor ex:5c8a4a5e-00b2-4630-8d8b-06937a71ba6d ; # T-101 tpl:hasShapeType rdl:RDS2225772 ; # SPHERE(shape) tpl:hasDimensionType rdl:RDS358289 ; # RADIUS tpl:hasPropertyType rdl:RDS373094 ; # LENGTH tpl:valPropertyValue "10"^^xsd:decimal ; tpl:hasScale rdl:RDS1332674 ; # METRE meta:valEffectiveDate "2021-11-17T13:55:00Z"^^xsd:dateTime . # IN-SHAPE-300.xml # EXAMPLE - Tank T-101 # has a shape of a sphere # represented with code # in CSG format # composed from given Part 3 class definitions. (other definitions also possible) ex:ed497e29-3504-43d3-a4aa-a67cddd3aa18 rdf:type tpl:DefinitionOfShapeOfIndividual ; tpl:hasPossessor ex:5c8a4a5e-00b2-4630-8d8b-06937a71ba6d ; # T-101 tpl:hasShapeType rdl:RDS2225772 ; # SPHERE(shape) tpl:hasShapeDefinition "(shape-defining code amalgated from Part 3 class definitions)" ; tpl:hasRepresentationForm exrdl:R85475 ; # includes CSG tpl:hasGeometryDataSet ex:94228079-ec37-4603-90b8-b4432f3628a6 ; # set of defining Part 3 classes meta:valEffectiveDate "2022-02-25T17:07:00Z"^^xsd:dateTime .

    #Templates about one or more PossibleIndividuals, related to: STREAM

    # IN-STRM-100.xml # EXAMPLE - Stream S35 has vessel V-120 as a source. ex:d1e8df0f-95f7-440f-a5f7-5a5480aa8fec rdf:type tpl:StreamHasSource ; tpl:hasStream ex:e08c0c53-46f1-4685-aa4f-ede87cd51fdd ; # S35 tpl:hasSource ex:1b0ba06c-caf4-40d5-996d-bdab315d5ce4 ; # V-120 meta:valEffectiveDate "2022-02-26T11:48:00Z"^^xsd:dateTime . # IN-STRM-200.xml # EXAMPLE - Stream S35 has tank T-101 as a destination. ex:b5db285b-2565-4f8f-9e3b-c58d0b28d171 rdf:type tpl:StreamHasDestination ; tpl:hasStream ex:e08c0c53-46f1-4685-aa4f-ede87cd51fdd ; # S35 tpl:hasDestination ex:d12f07ff-1a76-4b49-925d-081f885116e1 ; # T-101 meta:valEffectiveDate "2022-02-26T11:48:00Z"^^xsd:dateTime . # IN-STRM-300.xml # EXAMPLE - Stream Nh-43822 # at the inlet of P-101 # has a pressure of 6.8 barg ex:b4111e7c-e186-42c0-b41b-c3337c02a8b2 rdf:type tpl:PropertyOfStreamAtLocation ; tpl:hasStream ex:1ff912cb-cc24-4806-91c7-c456996f7bd5 ; # StreamNh-43822 tpl:hasLocator ex:e0ee58d1-0809-4d10-81e3-297ad4bbbd15 ; # Pump inlet P-101-IN tpl:hasPropertyType rdl:RDS354194 ; # PRESSURE tpl:valPropertyValue "6.8"^^xsd:decimal ; tpl:hasScale ex:RDS1348874 ; # BAR GAUGE meta:valEffectiveDate "2022-03-26T12:06:00Z"^^xsd:dateTime . # IN-STRM-400.xml # EXAMPLE - The actual Stream STR-43738 # is a member of Stream Class S5 (in Process Design), # "true" meaning that that part of the plant Operations conforms with its design. ex:35da20ea-82e4-4bef-b3d6-27d70ca742c1 rdf:type tpl:ActualStreamCompliesWithProcessDesignStreamYesNo ; tpl:hasStream ex:b1220073-3689-4222-8cbc-82f8ff778b91 ; # STR-43738 tpl:hasStreamType ex:6a03b9e7-9869-4455-96b0-11fe27b843f6 ; # S5 tpl:valComplianceYesNo "true"^^xsd:boolean ; meta:valEffectiveDate "2022-02-26T13:45:00Z"^^xsd:dateTime .

    #Templates about one or more PossibleIndividuals, related to: STRUCTURE

    # IN-STRUC-060.xml # EXAMPLE - John Doe is a member of the Construction Crew. ex:d135e2d5-8672-486e-8538-09b54cde9567 rdf:type tpl:CompositionOfAnIndividual ; tpl:hasWhole ex:aa77d995-cea8-4e11-a300-e6d59444cd7b ; # Construction Crew (an Organization) tpl:hasPart ex:365804a8-b08d-45e2-9e8b-2ac281604096 ; # John Doe meta:valEffectiveDate "yyyy-mm-ddThh:mm:ss.sZ"^^xsd:dateTime . # IN-STRUC-065.xml # EXAMPLE - The concentration of dissolved salts in my stream of seawater (its salinity) is about 3.5% of the weight of seawater. ex:77e35088-423d-4bf7-93c8-5307b338587e rdf:type tpl:IndividualHasCompositionPartPercentage ; tpl:hasWhole ex:f77d91b7-3ada-4d80-9cc4-3ea9f7947061 ; # myStream of SEAWATER tpl:hasPart ex:3afa433d-bf26-4bf7-b0df-940280aba120 ; # the content of SALT in myStream tpl:hasPercentageType rdl:RDS16430480 ; # WEIGHT PERCENTAGE tpl:valPartPercentageValue "3.5"^^xsd:decimal ; tpl:hasScale rdl:RDS16689948 ; # WEIGHT PERCENT meta:valEffectiveDate "2021-11-17T15:23:56Z"^^xsd:dateTime . # IN-STRUC-080.xml # EXAMPLE - The PIPE TO EQUIPMENT CONNECTION between NonActual P-101 and the NonActual line FZ-17801c # is implemented by # the PIPE TO EQUIPMENT CONNECTION between Actual P-101/AN738284 and # the Actual line FZ-17801c. ex:dad999d9-6f94-4f65-af34-237c2de7a827 rdf:type tpl:ImplementationOfNonActualRelationship ; tpl:hasNonActualObject1 ex:f768ca3a-84d0-4725-b3b0-78a11c11a0a0 ; # P-101 tpl:hasNonActualObject2 ex:796e97db-5a14-46ec-9a10-1dac6166560d ; # non-actual FZ-17801c tpl:hasActualObject1 ex:5d7176ac-4f2e-410f-898d-1d4cdd8bcfdb ; # P-101/AN738284 tpl:hasActualObject2 ex:155108a1-e00e-4d1c-81ff-714005646727 ; # actual FZ-17801c tpl:hasRelationshipType rdl:RDS2229357 ; # PIPE TO EQUIPMENT CONNECTION meta:valEffectiveDate "2023-02-15T13:45:00Z"^^xsd:dateTime . # IN-STRUC-120.xml # EXAMPLE - Insulation layer FZ-17801c-INS # is a part in an arrangement # with process line FZ-17801c, # a relationship classified as ARRANGEMENT BY COVERING. ex:cc6b7f6f-57a5-4404-a624-c0196c0652a8 rdf:type tpl:ArrangementOfAnIndividual ; tpl:hasWhole ex:03f7b927-ad23-4e64-a884-4ee756fcdf01 ; # FZ-17801c tpl:hasPart ex:3dfebdad-645e-44f2-8638-dd9e315976c6 ; # FZ-17801c-INS tpl:hasArrangementType rdl:RDS2225961 ; # ARRANGEMENT BY COVERING meta:valEffectiveDate "2021-11-17T15:05:00Z"^^xsd:dateTime. # IN-STRUC-140.xml # EXAMPLE - The actual pump that implements P-101 # is a member of # the EnumeratedSetOfIndividual 'Corrosion Loop CL-07' ex:179003ad-de09-4bd2-aac2-bd8c1004cb9f rdf:type tpl:EnumerationOfIndividual ; tpl:hasMember ex:39bdeb68-99b8-4eaf-bcb1-b26d44ae3b8b ; # AN-443723 tpl:hasSet ex:db788883-b1b3-4931-b590-9a48d16142d5 ; # CL-07 meta:valEffectiveDate "2022-02-17T15:05:00Z"^^xsd:dateTime . # IN-STRUC-180.xml # EXAMPLE - Impeller P-101-IMP # is an assembly part of # pump P-101 ex:e70e5fea-f44e-4d02-8f89-23c743c7eb40 rdf:type tpl:AssemblyOfAnIndividual ; tpl:hasWhole ex:ab63e420-d1df-4543-8514-619e839d734b ; # P-101 tpl:hasPart ex:1617015f-69dd-4262-a762-47ed5574d27e ; # P-101-IMP meta:valEffectiveDate "2021-01-14T17:26:00Z"^^xsd:dateTime . # IN-STRUC-240.xml # EXAMPLE - Impeller P-101-IMP # is an assembly part of # pump P-101, # and that is validated against the instance of ClassOfAssemblyOfIndividual that defines that centrifugal pumps have one or more impellers. ex:435e1575-d402-402c-8645-4966281c3015 rdf:type tpl:ClassifiedAssemblyOfIndividual ; tpl:hasWhole ex:ab63e420-d1df-4543-8514-619e839d734b ; # P-101 tpl:hasPart ex:1617015f-69dd-4262-a762-47ed5574d27e ; # P-101-IMP tpl:hasAssemblyType exrdl:R47383282 ; # 'CENTPUMP HAS IMP', defined in local RDL extension meta:valEffectiveDate "2021-01-14T17:26:00Z"^^xsd:dateTime . # IN-STRUC-300.xml # EXAMPLE - Line RZ80183 # has 6 to 10 # PIPING COMPONENTS ex:786aa3c1-e407-4e1c-b925-762dabe56510 rdf:type tpl:IndividualHasComponentCountByRange ; tpl:hasIndividual ex:eb88fb65-2cd7-4897-adc2-103d95eec07d ; # Line RZ80183 tpl:hasClassOfWhole rdl:RDS2223299 ; # PROCESS LINE tpl:hasComponentType rdl:RDS2221161 ; # PIPING COMPONENT tpl:hasCountRange ex:R4589340 ; # Cardinality 6:10, defined in local RDL extension meta:valEffctiveDate "2021-09-21T13:33:00Z"^^xsd:dateTime . # IN-STRUC-360.xml # EXAMPLE - Line Segment RZ80183-S3 has an (unidentified) injection point. ex:5ca2cea3-df22-4633-86f1-8c4ebfb4b97c rdf:type tpl:PartInAssemblyOfIndividualApplicableYesNo ; tpl:hasIndividual ex:aada84df-c7d0-4579-a976-8f8e5a03a487 ; # RZ80183-S3 tpl:hasClassOfWhole ex:1006670d-4c29-4a80-9cdc-61ffdd3333f0 ; # CO-RZ80183-S3 (the requirements class of RZ80183-S3) tpl:hasClassOfPart rdl:RDS2224587 ; # INJECTION POINT tpl:valApplicableYesNo "true"^^xsd:boolean ; meta:valEffectiveDate "2015-01-19T11:37:00Z"^^xsd:dateTime . # IN-STRUC-420.xml # EXAMPLE - Actual Process Line RZ80183 # has a # PIPE DENT # with Maintenance Identifier 'MI-342387' ex:5444efd1-c952-4da5-b523-7572bab67ab6 rdf:type tpl:FeatureOfIndividual ; tpl:hasWhole ex:aada84df-c7d0-4579-a976-8f8e5a03a487 ; # Actual Process Line RZ80183 tpl:hasPart ex:c0468b9d-8d4b-4ab6-b5b1-6dd8f24460f0 ; # Pipe dent MI-342387 meta:valEffectiveDate "2022-01-22T11:43:00Z"^^xsd:dateTime . # IN-STRUC-480.xml # EXAMPLE - Thermowell TW-132 doesn't have a fin NOTE - The non-existing fin can't have an identifier, so is modeled as 'unidentified member of ...' ex:df8a0094-5bc5-49b3-8b38-d784faa41b3e rdf:type tpl:FeatureOfIndividualApplicableYesNo ; tpl:hasWhole ex:5380738e-da12-490f-9463-a830a590ff08 ; # TW-132 tpl:hasPartType rdl:RDS2223666 ; # HEAT TRANSFER FIN tpl:valApplicableYesNo "false"^^xsd:boolean ; meta:valEffectiveDate "2022-03-01T16:47:00Z"^^xsd:dateTime . # IN-STRUC-540.xml # EXAMPLE - The flange at the end of Line RZ17801-OUT # is directly connected # classified as a FLANGED CONNECTION # to the inlet flange of Pump P-101-IN ex:b42d081c-24ae-4d22-a908-6ef211d913f9 rdf:type tpl:ClassifiedDirectConnectionOfTwoIndividuals ; tpl:hasSide1 ex:a1d691f2-06cc-45d9-a579-201f6f614e70 ; # Line RZ17801-OUT tpl:hasSide2 ex:9906c494-f186-43c8-bde8-5f24b050c468 ; # Pump P-101-IN tpl:hasDirectConnectionType rdl:RDS2229203 ; # FLANGED CONNECTION tpl:hasDirectConnection ex:55c7c816-9df6-46b9-b41d-2d5938893ef7 ; # auto-generated, for use in template IndividualUsedInADirectConnection, if so required meta:valEffectiveDate "2022-03-01T17:15:00Z"^^xsd:dateTime . # IN-STRUC-660.xml # EXAMPLE - Full Face Graphite Gasket - DIN 2573 PN6 - 12" (NB 300) # is used in the direct connection # between the flange at the end of Line RZ17801-OUT and the inlet flange of Pump P-101-IN (see above) ex:af42ba77-0e34-44e8-9ba2-e114adfd6018 rdf:type tpl:IndividualTypeUsedInADirectConnection ; tpl:hasUsedIndividualType asme:RDS535184 ; # FLAT RING GASKET ASME B16.21 CLASS 150 NPS 12 tpl:hasDirectConnection ex:55c7c816-9df6-46b9-b41d-2d5938893ef7 ; # the 'hasIndirectConnection' of tpl:ClassifiedDirectConnectionOfTwoIndividuals tpl:hasUsageType exrdl:R459332 ; # an subclass of rdl:RDS2229358 ("GASKET USED IN FLANGED CONNECTION") defined in a local RDL extension meta:valEffectiveDate "2022-03-04T14:34:00Z"^^xsd:dateTime . # IN-STRUC-600.xml # EXAMPLE - Preheater E-132 # is indirectly connected, # classified as an INDIRECT CONNECTION VIA PIPING, # with Crystallizer S-131 ex:1e401b9c-b4e2-4c6b-83ce-42e333183375 rdf:type tpl:ClassifiedIndirectConnectionOfTwoIndividuals ; tpl:hasSide1 ex:dfc94e5e-79f5-4f83-b842-1e953cd9e9f2 ; # E-132 tpl:hasSide2 ex:f9e60bea-b804-4b4e-847c-a137387b5281 ; # S-131 tpl:hasIndirectConnectionType rdl:RDS2220200 ; # INDIRECT CONNECTION VIA PIPING tpl:hasIndirectConnection ex:ca95ff1a-609a-4c1f-9833-f50c968b234f ; # auto-generated, for use in template IndividualUsedInAnIndirectConnection, if so required meta:valEffectiveDate "2022-03-01T17:15:00Z"^^xsd:dateTime . # IN-STRUC-720.xml # EXAMPLE - Process Line RZ80183 # is used for the indirect connection # of Preheater E-132-OUT # with Crystallizer S-131-IN ex:5250caec-bd89-4cff-bdde-69166ad5a4f0 rdf:type tpl:IndividualUsedInAnIndirectConnection ; tpl:hasUsedIndividual ex:aada84df-c7d0-4579-a976-8f8e5a03a487 ; # Actual Process Line RZ80183 tpl:hasIndirectConnection ex:ca95ff1a-609a-4c1f-9833-f50c968b234f ; # defined in ClassifiedIndirectConnectionOfTwoIndividuals (see above) tpl:hasUsageType rdl:RDS2220300 ; # PIPING USED IN INDIRECT CONNECTION meta:valEffectiveDate "2021-09-21T11:27:00Z"^^xsd:dateTime . # IN-STRUC-780.xml # EXAMPLE - Individual set of 100 ea. HEAVY HEX BOLT ASME B18.2.1 NS 2 ex:c99e7bea-5c78-4bb4-bc8b-733d2ce42138 rdf:type lci:InanimatePhysicalObject, dm:ActualIndividual, dm:WholeLifeIndividual, lci:EnumeratedSetOfIndividual, rdl:RDS2229359 ; # COLLECTION rdfs:label "Set of 100 ea. HEAVY HEX BOLT ASME B18.2.1 NS 2" ; meta:valEffectiveDate "2021-09-21T14:05:00Z"^^xsd:dateTime . ex:fbf21000-b8d1-4841-8753-98f490e61cf4 rdf:type tpl:AggregateOfMonotypeIndividual ; tpl:hasAggregate ex:c99e7bea-5c78-4bb4-bc8b-733d2ce42138 ; # above declared aggregate tpl:hasCollectorType rdl:RDS2220129 ; # COLLECTION OF INDIVIDUAL PHYSICAL OBJECTS tpl:hasObjectType asme:RDS847394 ; # HEAVY HEX BOLT ASME B18.2.1 NS 2 tpl:valAggregateCount "100"^^xsd:nonNegativeInteger ; meta:valEffectiveDate "2021-09-21T14:05:00Z"^^xsd:dateTime . # EOF
.
